how to repair 4 wheel drive

by Prof. Bella Durgan III Published 2 years ago Updated 2 years ago

Clean the components of the system Lubricate the locking hubs Inspect the transfer case The technician will also drain fluids out of the differentials and give them fresh fluid. 4 Wheel Drive Repair Sometimes this system will be in need of repairs, especially from tough terrain or off-road driving.

Full Answer

Is 4 wheel drive faster than 2 wheel drive?

Winter tires with chains on a 4 wheel drive will offer improved traction on icy roads. Now we’ve established that driving in a 4 wheel drive will not allow you to drive faster or brake later than vehicles with 2-wheel-drive drivetrains.

Is AWD and 4WD the same thing?

All-wheel drive, or AWD, refers to a system where all four wheels can gain traction independently of each other. The difference between AWD and 4WD is that AWD is typically always on while you have the ability to toggle between having 4WD on and off. 4WD is an addition you’ll usually find on a truck, while AWD is more for cars and SUVs.

Which is better 4WD or AWD?

It all depends on the type of driving situations which you most frequently plan to encounter and how you plan to use your vehicle. In general, 4WD is preferred for serious, heavy-duty off-roading situations, whereas AWD is excellent for maximizing performance all around but not necessarily off-road.

How do you get into 4 wheel drive?

When is it 100% SAFE to switch from 2H to 4 wheel drive

  • Wet roads. If you live in a part of the world that experiences heavy rain on a regular basis or your winter season is very wet then you most likely ...
  • Snowy Icy roads. Driving your 4WD on a low-traction snow road is the ideal opportunity to switch on your 4H functionality.
  • Sand tracks. ...
  • Beach driving. ...
  • Muddy tracks. ...


What would cause my 4 wheel drive not to work?

An electrical fault such as a corroded wire or faulty 4WD dial/switch, A component failure such as a faulty transfer case module or actuator. A seized differential caused by poor lubrication. A leak in the vacuum hoses (older traditional 4WD systems)

How much does it cost to fix a 4 wheel drive system?

If you just have to replace it, that would be anywhere from $500 to $1000. However, you can also expect the cost of the parts to be around half that number and the labor costs around $200. So even for a simple repair, you can end up with around $1500-$1700 invested in the Drive Shaft Repair process.

How do you service a four-wheel-drive?

0:2310:03How To: service your 4wd system - YouTubeYouTubeStart of suggested clipEnd of suggested clipSo these have a drain plug located on a very very bottom of it some other ones have a bolt ring.MoreSo these have a drain plug located on a very very bottom of it some other ones have a bolt ring. Which you can usually locate. Around through here where you have to remove the rear cover.

How do you diagnose a 4WD problem?

Turn your wheels all the way to one side and drive forward. You should feel the vehicle bind or resist rolling forward smoothly. If you can not feel the vehicle resisting during the turn then your 4WD is probably not working.

Can I still drive with service 4wd light on?

In order to avoid this, make sure to shift completely before taking off for a drive. If you believe you have shifted into gear properly but the light is still on, get to a professional mechanic as soon as possible, as this may indicate a transmission issue.

Is it worth fixing a transfer case?

If the damage to your transfer case is minor, it may be worth fixing it. However, if the damage is significant or if replacement parts are expensive, it may be best to replace the entire unit. Only you can decide whether it is worth fixing your transfer case.

What does a 4 wheel drive service consist of?

4 X 4 Transmission Services Our 4x4 services include: Draining and refilling the Transfer Case with fresh, clean fluid. Draining and refilling the Front Differential with fresh, clean fluid. Draining and refilling the Rear Differential with fresh, clean fluid.

How often should 4WD be serviced?

In some cases, no more than 30-36,000 miles. And in some cases it may be as frequently as every 15,000 miles. Also look for any kinds of leaks when you're under it.

What does a four-wheel drive service consist of?

Our four-wheel-drive service, performed by our ASE-Certified Technicians, includes inspecting the transfer case, locking hubs, final drive, drive axles, and both front and rear differentials for leaks and wear.

What does a failing transfer case sound like?

Strange Grinding, Growling or Humming Noises If you hear grinding, growling, or humming noises that change with your vehicle speed, it may be coming from the transfer case. This could indicate a low fluid level or some mechanical problem such as bad bearings, loose chains or damaged gears.

What happens if transfer case is low on fluid?

Difficulty changing gears – Low or dirty transfer case fluid can affect your transmission's ability to shift gears. It can also result in your car unexpectedly falling out of four-wheel drive. Loud noises while driving – As the transfer case fluid loses its lubricating properties, friction will occur inside.

How do you test a transfer case shift motor?

Switch on the ignition and observe the transfer case shift control indicators, you should notice a flash. You also need to diagnose some system circuits if you do not notice any flash. Check for battery and ignition voltage. Check the transfer case shift control switch connector and the ground circuit for earth.

Are 4 wheel drives expensive?

Four-wheel drive vehicles are more expensive than two-wheel drive. Four-wheel drive vehicles consume more fuel because four-wheel drive systems use more energy.

How much does it cost to fix a transfer case?

The transfer case shifts power between axles depending on road conditions. Replacing a transfer case is an expensive repair that usually costs anywhere from $2,300 to $2,900. Most people end up paying around $2,500 to replace a transfer case, but the total price may be slightly more or less depending on the vehicle.

Is all-wheel-drive expensive to maintain?

Yes, all-wheel drive systems are more expensive to maintain than front-wheel drive cars. There are more parts to an all-wheel drive vehicle than a front-wheel drive car, resulting in more complexity and a higher chance of one component requiring care.

What are the problems with all-wheel-drive?

All-Wheel-Drive Problems: Down & DirtyYou can hear a grinding at highway speeds.You have a transfer case over-temp warning on the dash.You might experience blinking lights in the drive selector area (model specific)You might hear & feel a bang-bang-bang sensation under hard acceleration.More items...

What is 4 wheel drive?

Four wheel drive (4wd) trucks, cars and SUVs are able to handle different types of terrain because the system gives power to all four of the vehicle’s wheels at once, whereas normally vehicles just give power to two. Four wheel drive vehicles can have different costs involved, and need proper maintenance service and repair.

How many points does a Meineke 4 wheel drive inspection have?

Visit your local Meineke Care Center to receive a 23-point inspection to ensure your entire vehicle is in proper operating condition.

Do you need to maintain a four wheel drive system?

The different parts of the four-wheel drive system need regular maintenance to keep them working properly . A technician will typically:

What to do when you service a 4WD?

When you service the 4WD make sure all electrical connections are properly cleaned and sprayed with a good quality electrical silicon spray to prevent moisture build-up. Your 4-wheel-drive has hundreds of electrical connections sending various signals from sensors.

Why won't my 4WD engage?

Modern 4WD makes use of electronic switches and a solenoid which needs to be inspected if the 4×4 light is constantly blinking on the dash. Inspect all related wires for corrosion. Engage your 4WD system at least once a month to keep the system well lubricated.

What is an actuator in 4WD?

Many modern 4WD actuators are electronic that makes use of an electronic solenoid to engage the actuator gears to lock the diff. Older model 4-wheel drive actuators made use of vacuum hoses that use pressurized air and works together with the transfer case to activate the gears and lock the differential.

What is a 4 wheel drive actuator?

The actuator of a 4-wheel-drive is designed to lock the differential once the driver engages 4WD by means of a switch from inside the cabin. The 4WD axle actuator is housed on the differential and contains the gears and shift fork required to lock the differential once it receives the signal. Once engaged the axle will rotate as one complete unit, drastically improving off-road traction.

Why do you need to lubricate the gears on a shift fork?

All the moving components inside the actuator like the shift fork, locking collar and gears need to be regularly inspected and lubricated to protect them from moisture setting in , causing internal damage.

How does differential locker work?

When the driver activates differential locker by means of a switch, it triggers a process that connects drive-shafts to function as one locked unit. The actuator uses a shift fork that slides a locking collar over two separate gears. This essentially engages 4WD mode. Most modern 4-wheel-drives with 4A (Automatic) completes this process automatically.

Why does diff oil break down?

The below 3 reasons are mainly why diff oil breaks down faster. You regularly drive on rough, wet off-road tracks. You launch a boat regularly and the axle might be partially submerged in water. You place a lot of load on the drivetrain by regularly driving in deep snow, thick sand or boggy mud.

What is 4 Wheel Drive?

At its most basic level, 4WD is a vehicle transmission system that provides power to all four wheels of a vehicle at the same time. In order to answer the question, “What is 4 wheel drive,” we must differentiate between part-time and full-time systems.

What are the advantages of 4WD?

The main advantages is the off road superiority of a 4WD and its ability to take you places that smaller cars cannot go. Whatever terrain you have in mind – gravel, rocks, sand dunes, mud, hills, ice, or snow – a ladder frame 4WD is up to the challenge. A 4WD provides enhanced traction and better control in dangerous driving conditions. And for those who enjoy the off-road experience, a 4WD delivers plenty of fun and thrills.

Does 4WD help with acceleration?

While a 4WD carries many benefits, it is also important to recognize its disadvantages. While 4WD may help with acceleration, it does not make it easier to stop or turn on low traction surfaces. If you are concerned about that, invest in some all-terrain tires.

Can you replace a transfer case?

Replacing your transfer case is not the easiest task, but it can be done if you give yourself plenty of time and space.

Is 4WD mandatory?

For the mud bogging trucks with 8" lifts, 4WD is mandatory. For the hardcore rock crawler that needs traction while driving vertically, 4WD is a must have. For the average dude who occasionally goes camping with his family, 4WD is peace of mind.

What does the service 4 wheel drive message mean?

When the trouble codes are stored and the Service 4 Wheel Drive Message is displayed, the transfer case is inoperative for the rest of that particular key cycle. It will test again and reset the message on the next key cycle if the problem hasn’t been fixed. The codes may be stored with or without you requesting a transfer case shift. The codes and message may also be set during normal driving conditions in Auto 4WD, 4HI or 4LO.

What is the service bulletin number for GM 4 wheel drive?

GM has issued a service bulletin # 09-04-21-001 to address a Service 4 Wheel Drive Message condition on the vehicles listed below. In addition to the Service 4 Wheel Drive Message, you may also have a C0387 or a C0569 trouble code stored.

What is transfer case motor?

The transfer case encoder motor is a bi-directional DC motor. When energized through motor control A or motor control B, the ground connection is provided by the opposing motor control circuit, which is then grounded through the transfer case control module (TCCM) ground circuit. The transfer case motor rotates the actuator shaft which moves the transfer case two/four wheel drive actuator cam and transfer case high/low shift fork to shift the transfer case between the following modes or ranges: 2 HI, 4WD HI, 4WD LOW, Neutral
