how to repair a lamp light switch

by Mr. Broderick Klocko Published 2 years ago Updated 2 years ago

How to Fix a Lamp Switch

  1. Unplug the lamp. If the lamp has been on, let it sit for 15 to 20 minutes so the light bulb is cool to the touch.
  2. Grab the metal light bulb holder and unscrew it from the switch casing by turning it counterclockwise.
  3. Look at the switch. You will see that the power cord actually consists of two separate electrical wires that are attached to the switch by small brass screws.
  4. Grab the two wires near where they turn down into the body of the lamp and pull up. The electrical cord will be pulled up through the lamp.
  5. Unscrew the two brass screws and disconnect the wires from the switch.
  6. With a pair of needle nose pliers, remove the collar on the outside stem of the switch. Then unscrew the stem and remove it.
  7. Install your replacement switch by reversing these steps. Reassemble your lamp and you are done. ...

How to repair a three-way switch on a lamp?

How to Repair a Three-Way Switch on a Lamp

  1. Disconnect the lamp's power cord from the electrical outlet. Remove the lampshade, the shade-mounting rod and the light bulb from the lamp.
  2. Slip a small flat-head screwdriver in between the bottom of the lamp socket and the base, and gently pry the socket from the base.
  3. Unscrew the two wire connections and disconnect the two wires.

More items...

How to install or replace an inline lamp switch?

Method 1 Method 1 of 2: Replacing a Socket Switch

  1. Purchase a new socket switch from a hardware store. Your new switch can be whatever type you prefer, regardless of the existing switch.
  2. Unplug the lamp before you begin repairs. Never take chances when you’re working with electricity. ...
  3. Remove the shade, bulb, and the wire that holds the shade in place. ...

More items...

How to replace a 3 way lamp switch?

What to do:

  • Make sure you unplug your lamp before touching it.
  • Remove the cover of the lampshade, light bulb, and mounting rod.
  • Remove the screws between the bottom of your lamp base and socket.
  • Gently detach the socket from the base.
  • Gently lift the socket to unveil the wirings of the lamp.
  • Once you slide the cardboard tube, you will see the wire connections.

More items...

How to rewire a lamp?

Steps for Rewiring a Floor Lamp:

  • Firstly, you need to pull the plug out to disconnect the power from the socket to
  • Remove the shade if present above the bulb (if not present, skip to step 3)
  • Pull out the bulb from the floor lamp.
  • Take out the socket of the lamp.
  • Disconnect the power cord.
  • Remove the insulation of the wire.
  • Attach wires to the terminal of the floor lamp

More items...

What to do if your lamp is flickering?

Where is the switch socket located on a lamp?

How much does it cost to replace a socket switch?

What does the circle on the lamp on a lamp stand mean?

Why is a rotary switch used?

Can you replace a lamp switch?

Can you wrap wires around screws?

See 2 more


How do you fix a broken light switch on a lamp?

0:397:38How To Replace a 3 Way Lamp Switch - YouTubeYouTubeStart of suggested clipEnd of suggested clipSo what we have to do is replace this old broken one with this new one little switch here simplyMoreSo what we have to do is replace this old broken one with this new one little switch here simply unscrews unthread that this sleeve comes up this is just crimp down. So just work it up.

Can a switch on a lamp be repaired?

You can fix a lamp switch easily. Every lamp switch either comes loose at some point during its lifetime or simply wears out. Fortunately, not only is fixing a lamp switch easy, but all you need are a few simple tools and possibly an inexpensive replacement switch as well.

What causes a lamp switch to stop working?

A switch circuit that doesn't operate correctly may simply have a tripped breaker or blown fuse. Head to the electrical service panel and locate the breaker or fuse. If the breaker is tripped, reset it; or if the fuse is blown, replace it with an exact duplicate.

How do you change the switch mechanism on a lamp?

1:479:43How to replace a lamp switch and socket - YouTubeYouTubeStart of suggested clipEnd of suggested clipHere. It's a matter of pinching. And prying. And that she'll comes right off like that sometimes IMoreHere. It's a matter of pinching. And prying. And that she'll comes right off like that sometimes I like to take and push some of the wire up into the base.

How do you take apart a light switch?

1:483:09How To Remove A Light Switch-DIY Electrical - YouTubeYouTubeStart of suggested clipEnd of suggested clipInto these little slots one right there underneath that hole and one right there underneath thatMoreInto these little slots one right there underneath that hole and one right there underneath that hole just insert a small flathead.

How do you open a inline lamp switch?

0:295:49Replacing the Switch on a Lamp (How to) - Lava Lamp ExampleYouTubeStart of suggested clipEnd of suggested clipAnd the first thing i do is of course i unplug the lamp. So that there's no more electricity flowingMoreAnd the first thing i do is of course i unplug the lamp. So that there's no more electricity flowing. So then the next thing is i'm going to take a look close look here at the switch. And there's a

How can you tell if a light switch is bad?

Turn the switch lever on and off. The tester should light up when the switch lever is in the on position but should not light up when the switch lever is off. If it doesn't exhibit this behavior, it indicates the inner connections are bad and that the switch needs to be replaced.

What are four types of lighting switches?

20 Types of Light Switches1) Toggle Switch. What is this? ... 2) Decorative or Rocker Switch. What is this? ... 3) Single-Pole Switch. What is this? ... 4) Double-Pole Switch. What is this? ... 5) Pole Receptacle Combo Switch. What is this? ... 6) Dimmable Switch. What is this? ... 7) Push-Button Light Switch. ... 12) Sound-Activated Light Switch.More items...•20 Types of Light Switches: Toggles, Dimmers, & More - Worst Roomhttps://worstroom.com › types-of-light-switcheshttps://worstroom.com › types-of-light-switches

How do you fix a 3 way lamp socket?

0:061:15How to Install a Three-Way Lamp Switch - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd pop it off loosen the terminal screws and remove the wires from the old socket. Then attach theMoreAnd pop it off loosen the terminal screws and remove the wires from the old socket. Then attach the wires to the terminals on the new socket. Finally replace the socket.How to Install a Three-Way Lamp Switch - YouTubehttps://www.youtube.com › watchhttps://www.youtube.com › watch

How do you remove a switch switch plate?

Using a flathead screwdriver, carefully pry off the switch cover and use a Phillips head screwdriver to unscrew the existing switch from the fittings. If you choose to remove the switchplate yourself, you can expose yourself to severe safety risks during the process, or as soon as you turn back the power.Electrical DIY: Steps in Changing a Light Switch in Australiahttps://hillsdistrictelectrician.com.au › electrical-diy-steps-i...https://hillsdistrictelectrician.com.au › electrical-diy-steps-i...

Why does my 3 way lamp switch not work?

The problem can be that the bulb is shot, or that the power isn't getting to it, or that there's something wrong with the electrical path back to the ground—the neutral wire. First of all, it doesn't matter what kind of light bulb you're dealing with.

How do you fix a shorted out lamp?

0:211:30How To Fix A Short In A Light Socket - YouTubeYouTubeStart of suggested clipEnd of suggested clipThere's usually a nut or stem that holds the socket on there. And then there'll be two screwMoreThere's usually a nut or stem that holds the socket on there. And then there'll be two screw terminals on the back side where the wires are attached.

How to remove a lamp switch from the inside?

With a pair of needle nose pliers, remove the collar on the outside stem of the switch. Then unscrew the stem and remove it. You can now remove the switch itself from inside the lamp.

How to make sure your lamp switch is the same?

Take your old switch in to your local hardware store to make sure that you are getting an exact match for your lamp switch. Often, the same model lamp may have a different type lamp switch in it depending on the factory or year in which it was made.

How to get electrical cord out of lamp?

Grab the two wires near where they turn down into the body of the lamp and pull up. The electrical cord will be pulled up through the lamp. You will want 6" of the cord extending above the lamp. Place a small piece of electrical tape on the extra cord to hold it. This way it will not fall back into the lamp body when disconnected from the switch leaving you the difficult task of trying to get it back out.

How to check if a lamp switch is faulty?

You will see that the power cord actually consists of two separate electrical wires that are attached to the switch by small brass screws. Reach in and see if you can wiggle either of the wires. If you can, tighten the screws with a small Phillips head, replace the metal bulb holder and bulb, plug the lamp in and test it. Often a faulty lamp switch is caused by the wires coming loose and does not need to be replaced. If the lamp does not work, repeat steps 1 and 2 to expose the switch again.

How to pull up a lamp cord?

Grab the two wires near where they turn down into the body of the lamp and pull up. The electrical cord will be pulled up through the lamp. You will want 6" of the cord extending above the lamp. Place a small piece of electrical tape on the extra cord to hold it.

How to unscrew a light bulb from a switch?

Grab the metal light bulb holder and unscrew it from the switch casing by turning it counterclockwise. Set the metal holder aside.

How to cool a light bulb?

Step 1. Unplug the lamp. If the lamp has been on, let it sit for 15 to 20 minutes so the light bulb is cool to the touch. Once the bulb is cool, remove it.

How to remove a light bulb from a lamp?

Squeeze and pull the socket shell to remove it from the lamp. The socket shell is the actual assembly where the switch is located and the light bulb screws in. On most lamps, you can squeeze the socket shell and pull upwards to remove it. If the socket shell is hard to remove, use a screwdriver to pry it loose.

What to do if your lamp doesn't come on?

If the lamp doesn't come on, check the connection in your switch and try again. If this doesn't help, you may need to replace the plug.

How to remove insulation from a switch?

Strip about 1⁄2 inch (1.3 cm) of insulation off of the wires. Use your wire cutters to make a notch in the wire insulation, then gently pull to remove it. Only take off as much insulation as you need to attach the wires to the screws in the switch.

How to tell if a switch is hot or neutral?

Locate the wires attached to the socket shell. There should be 2 wires attached to the switch. 1 is hot and the other is neutral. The hot wire is usually attached to a brass screw, and the neutral wire is usually attached to a silver screw. The neutral wire is usually marked in some way.

How to install a 3 way turn knob?

1. Purchase a new socket switch from a hardware store. Your new switch can be whatever type you prefer, regardless of the existing switch. For instance, if your lamp has a pull chain but you want to install a 3-way turn knob, all you have to do is buy a 3-way turn switch and a light bulb with 2 brightness levels.

How to remove old switch?

If you have to cut it in order to remove the old switch, strip the insulation and connect the cut ends of the neutral wire together. If you like, add a plastic connector to protect the wire at the location where you want your new switch to be.

How much does a socket switch cost?

You can buy a new socket switch from most hardware stores, and they usually cost around $2-$5 USD.

Why unplug a lamp from the wall?

Unplug the lamp from the wall to reduce the risk of electric shock.

How to get power cord out of lamp?

Partially peel back the felt or cork from bottom of the lamp to gain access to power cord. Take care to avoid tearing.

What happens when you remove a screw?

When the screws are removed, the threaded socket will pull out.

How to remove a lamp from the socket?

Unplug the lamp and remove the bulb. Next to the switch on the socket cover face will be a slight depression labeled "Press Here." This is a latch on the socket cover that , when pressed with a small screwdriver, the cover can be pulled up to expose the inner socket where the wires are. Press on the depression and pull the socket cover up and away.

What to do if your light bulb doesn't light up?

If at this point the bulb does not light up, the socket will need to be replaced. When the base cover is removed on an older lamp and the switch is clearly broken, the switch is non-repairable and will need to be replaced. Spray a small shot of silicone spray on the bulb threads before you screw it into the socket.

What is a table lamp switch?

Table lamp switches are usually designed in three different types. One is a do-it-yourself-friendly retro or antique lamp switch that comes apart with small screws; the other types include a modern sealed switch housed within a plastic case that does not come apart, and the socket stem switches that are common on the majority of table lamps. ...

How to grease a rotary switch?

Grease the entire mechanism with silicone spray grease if the switch turns hard. With the cover removed, spray a drop or two of grease around the rotary cam. Turn the cam several times to work the grease in. On many occasions, particularly on antique switches, the original grease dries up and the switch becomes hard or nearly impossible to turn. By adding grease, you lubricate the cam so it will turn freely and make contact with the copper fingers.

What happens when you remove the base cover on an old lamp?

When the base cover is removed on an older lamp and the switch is clearly broken, the switch is non-repairable and will need to be replaced.

How to unscrew retaining nut on switch?

Unscrew the retaining nut on the switch. In most cases they will unscrew by using the thumb and the forefinger, but in some cases small pliers may be needed to exert more pressure on the nut.

Can a retro antique switch be repaired?

Although the retro antique base types and socket stem switches have a better opportunity for repair if they malfunction, modern sealed lamp switches can sometimes be repaired while not having to open up the case.

How To Fix Floor Lamp Switch Socket?

Don’t try to become a superhero. Make sure that you have already removed the plug from the socket when you start your work.

How To Fix Floor Lamp Switch Cord?

Look for printing on the lamp cord to work out the dimensions switch you would like. Search for printing that says either SPT-1 or SPT-2. The printing is small, so you would possibly need to look carefully.

What to do if your lamp is flickering?

If you are dealing with a flicking lamp. You have to fix your lamp switch immediately.

Where is the switch socket located on a lamp?

On most lamps, the switch socket is located under the shade. So, don’t forget to remove the shade, bulb, and wires

How much does it cost to replace a socket switch?

You can find it on most hardware stores, whatever type you needed for your lamp. A new high-quality socket switch usually costs around $2 to $5 as WikiHow said.

What does the circle on the lamp on a lamp stand mean?

It may have a circle on one end to let the user know the lamp is on. While on the other end it has a horizontal dash line that indicates the lamp is off.

Why is a rotary switch used?

Usually, a rotary switch is used to control different electrical circuits with a single switch. Because it can move in a circle and is also stoppable in various positions. It is specifically designed to have many contacts happening at a time on a single switch position.

Can you replace a lamp switch?

Replacing a lamp switch is an easier and simplest project that can be tackled by anyone. While repairing a lamp switch could be a little bit difficult.

Can you wrap wires around screws?

Wrapping the wires around screws is easier with your fingers. But you have to make sure there is no visible portion of wires when you assemble the switch. Mistakenly if you exposed the wires too long, first cut the extra length and reattach the wires.
