Here is what to do:
- Remove the speedometer from the vehicle. This is often the most difficult task to do.
- If anyone has ever put oil or grease in/on the flexible shaft going to the transmission, the flexible shaft must be...
- Once the shaft and housing are clean and lubricated with graphite, you can repair the speedometer or, really, lubricate...
Full Answer
How much would it cost to repair a speedometer?
Issues with your sensors or your actual speedometer do not cost much but, if the issue lies deeper and requires additional diagnostics, you can expect to pay between $200 and $400. These prices are just an estimate and your particular case will be different depending on the issue.
Is there a way to reset the speedometer?
Tools and Parts Required:
- Screwdrivers
- Soldering iron, solder and a de-soldering pump
- Computer with Windows XP and serial port
- 8 pin DIP socket
- Serial programmer - Breadboard - Hookup wire - Female serial port header - 5V from computer power supply - 4.7K ohm resistors - 5V Zener diodes o Wire strippers
- Serial programming software (PonyProg freeware)
How do I get my speedometer recalibrated?
How do I get my speedometer recalibrated? You may recalibrate a speedometer in a few simple steps. Open the vehicle’s hood and locate the transmission. Unscrew the speedometer cable from the transmission’s tail shaft and use a crescent wrench to unscrew the bolt holding the gear housing cover in place.
How do you fix the speedometer?
You probly need to replace your VSS, Vehicle Speed Sensor. This is usually located on the top of the transmission. It should just unscrew and you can screw a new one in. This should fix the speedometer.

Can a speedometer be repaired?
If your vehicle's speedometer is found to be defective, instrument cluster removal will be necessary. This often involves the removal of select dash components, and associated hardware. One can then purchase a new/remanufactured instrument cluster, or choose to have their compromised cluster rebuilt.
What to do if speedometer stops working?
If your speedometer stopped working and stays at 0 MPH, you should have your car checked ASAP. The most common causes of a speedometer that stopped working include are a faulty speed sensor, a broken gear on the speedometer, damaged wiring, or a faulty engine control unit.
How do you fix a wrong mechanical speedometer?
0:234:03How To Fix A Misreading Speedometer - YouTubeYouTubeStart of suggested clipEnd of suggested clipSimply splicing into the speed signal wire or by using a plug-and-play kit that they.MoreSimply splicing into the speed signal wire or by using a plug-and-play kit that they.
How do you fix a bouncing speedometer?
4:347:01How To Fix A Shaky/Bouncing Speedometer [BEST CABLE LUBE]YouTubeStart of suggested clipEnd of suggested clipSo I cleaned off that spring cable and I actually put a bit of pressure to try and straighten thatMoreSo I cleaned off that spring cable and I actually put a bit of pressure to try and straighten that out and it is straighter now.
Is it illegal to drive a car with a broken speedometer?
A vehicle's speedometer must be kept free from any obstruction that may prevent it from being read and shall at all times it is used on a road be maintained in good working order.
Can a blown fuse stop the speedometer?
Bad Wiring or a Faulty Fuse If there's a bad fuse or a bad wire in your car and the speedometer's fuse stops functioning, the speedometer will drop to zero and stay there. A fuse can blow for various reasons, including a bad wiring job or wires getting wet due to exposure.
How do you calibrate a mechanical speedometer?
7:419:59Speedometer Calibration - YouTubeYouTubeStart of suggested clipEnd of suggested clipStart your vehicle release the switch. We'll be at 50 50 is the one for the instant. Calibration. SoMoreStart your vehicle release the switch. We'll be at 50 50 is the one for the instant. Calibration. So we're gonna push and hold the pointer will drop to zero. Now you're ready to go to the instant.
How does a mechanical speedometer work?
Inside a mechanical speedometer The magnet rotates with the shaft and its magnetic field attracts a metal drum to turn the speedometer needle against the force of a hair spring. The needle moves round the dial until the restraining force of the hair spring brings it to rest to give a reading of the road speed.
How much does it cost to get a speedometer fixed?
Because the cost of repairing a broken speedometer averages around $200, you'll likely want to replace it with a new one. This can run you about $250, but you'll have an entirely new unit. The most common cause of a malfunctioning speedometer is a problem with the speed sensor.
What causes a mechanical speedometer to bounce?
While you are driving, if you notice the needle on the speedometer jumps erratically from one number to another, the speedometer cable is most likely damaged or the sensors on the driveshaft are not accurately sending the signal through the cable.
What causes a speedometer to jump up and down?
You could have a problem with the speed sensor that provides information to the speedometer -- either with the sensor, the driven gear, or the wiring or connector to the system. A good diagnostic tool should be able to monitor sensor output and test the system.
What causes a bouncing speedometer?
Think of the speedometer cable as a long torsion bar. If it is binding inside of the sheath, it will bind-release-bind-release, etc. This causes the bouncing needle. When installing a new cable, avoid any sharp bends that may exacerbate binding.
How much does it cost to fix a speedometer on a car?
Because the cost of repairing a broken speedometer averages around $200, you'll likely want to replace it with a new one. This can run you about $250, but you'll have an entirely new unit. The most common cause of a malfunctioning speedometer is a problem with the speed sensor.
How much does it cost to replace a vehicle speed sensor?
The average cost for vehicle speed sensor replacement is between $275 and $318. Labor costs are estimated between $116 and $146 while parts are priced between $159 and $172. This range does not include taxes and fees, and does not factor in your specific vehicle or unique location.
Where is the fuse located for the speedometer?
1:402:54KIA OPTIMA SPEEDOMETER FUSE, SPEED SENSOR FUSE LOCATION ...YouTubeStart of suggested clipEnd of suggested clipSo there is a special fuse for the transmission. Control you need number two okay that fuse rightMoreSo there is a special fuse for the transmission. Control you need number two okay that fuse right here that controls that and that's this 15 amp fuse.
How much is a speedometer sensor?
Depending on the vehicle year, make and model, a speed sensor can cost as little as $7.92 or as much as $100. For most vehicles, the cost for a speed sensor is between $25 and $45.
What is the difference between a speedo and a driving gear?
The driving gear is also called the trans gear and is situated over the output while the driven gear is called speedo gear and is directly attached to this speedo cable. When undertaking speedometer repair, you need to replace this speedo gear. When you change both or one of the gears, you end up changing the cable speed.
How to connect a speedometer to a transmission?
Step 1 - Understand the Connection. Your vehicle speedometer is connected with the transmission through a speedo cable. Within the transmission are located two gears, namely the driving and the driven gear. The driving gear is also called the trans gear and is situated over the output while the driven gear is called speedo gear ...
When does a speedometer need to be calibrated?
on Nov 11, 2019. The standard speedometer gets calibrated at the factory, however, it may eventually become necessary to undertake speedometer repair if it doesn't seem to be measuring speed and mileage accurately. Using tire circumference as well as height, engineers are able to ensure the speedometer operates properly.
How big is a transmission gear?
Some of the gears can be as much as 3/4 inches in diameter while others could range between 1/2 and 1 inch in diameter. You need to measure the precise size needed because mixing up the two diameters would result in a mismatch. You can replace the other driving gear only after removing the tail shaft of the transmission.
Does the diameter of a tire affect the speedometer?
The diameter of the tire will have an impact on the speed shown on the speedometer and therefore impact the speedometer repair as well. Compared to smaller diameter tires, the larger tires will travel greater distances in the same time.
What does it mean when a gear has fewer teeth?
A driven gear with fewer teeth will speed up the speedometer reading; more te eth will slow down the reading. On the drive gear, it's the opposite-fewer teeth will slow down the reading and more teeth will speed up the reading.
What is a ratio adapter?
A mechanical ratio adapter is a small gearbox used to increase or decrease the rotation speed of the cable on a mechanical speedometer. Ratio adapters can be installed anywhere in the system, such as inline along the cable, or at the speedometer, but they are typically located at the transmission.
Where is the drive gear located?
The drive gear is a worm gear located in the transmission, running off the output shaft. It turns the driven gear, a pinion gear that is connected to the end of the speedometer cable. Changing the ratio between the drive gear and the driven gear will change the speedometer reading.
Do taller gears affect speedometer reading?
Similarly, taller gears (lower numerically) will have the same effect as taller tires, and the speedometer reading will be slower than actual. In either case, you need to figure out the amount of error in your speedometer and how to correct it. See all 11 photos.
Where to put chalk mark on car?
Roger Luckow suggests putting a chalk mark on the bottom center of the sidewall and on the pavement at that same point. Roll the car forward until the sidewall chalk mark is at bottom center again, and measure that point on the pavement from the starting point.
Is it dangerous to drive a hot rod with an incorrect speedometer?
Driving around with an incorrect speedometer can be dangerous and could earn you a ticket-not to mention ...
