There's not much apart from replacement to fix bad pitting in rods. You could try some low-temperature silver solder in the worst pits, then file the solder smooth with a flat file, and finish off with emery cloth tape. OzDozer, Feb 24, 2012
Full Answer
What is the best way to repair a worn shaft?
Restoring dimensions in a worn shaft is an easier task. Although overlaying with fused powder or copper alloys can be done with an oxyacetylene flame, without melting the shaft material, the process still softens the steel. Plasma thermal spray is the preferred method, because the shaft material is heated minimally.
Can epoxy fix pitting in rods and shafts?
However, the cost of these epoxies generally makes Cat parts look like Wal-Mart specials. The problem with trying to fix pitting in rods and shafts is that you need to prepare the surface in the pitted area so that the epoxy can bond to it satisfactorily. This is often impractical, because the pitting usually comprises lots of small holes.
How to repair a broken propeller shaft?
To fix this problem on large propeller shafts, we would perform a process called cladding in our machine shop. Cladding or shaft weld-over, is the process of repairing a worn or damaged area on a propeller shaft or rudder shaft.
Is there pitting on shafts and hydraulic cylinders?
Pitting on Shafts and Hydraulic Cylinders – when to repair or replace? It is a fairly common occurrence for us to find pitting on hydraulic cylinders or shafts that we work on in our shop at Straight Line Marine.
How do you fix a worn steel shaft?
1:315:17Build up a worn or undersize shaft - a quick and dirty fix - YouTubeYouTubeStart of suggested clipEnd of suggested clipContact bring her back go up a quarter of a turn or quarter to a half of a turn depending on howMoreContact bring her back go up a quarter of a turn or quarter to a half of a turn depending on how much kneeling you have to do bring it back in and you'll feel it bite into the shaft.
How do you spray weld a shaft?
2:5351:05SNS 300: Spray Welding a Blower Shaft - YouTubeYouTubeStart of suggested clipEnd of suggested clipWhat we'll do is just turn it down to just above the diameter of the threads. And it will machine aMoreWhat we'll do is just turn it down to just above the diameter of the threads. And it will machine a heavy sleeve and shrink a sleeve on there and then turn it back to size.
How do you fix a worn spline?
0:389:27Using Loctite 660 to repair a stripped splined shaft - YouTubeYouTubeStart of suggested clipEnd of suggested clipObviously have been worn down and they were filled with some kind of a gray epoxy jb weld orMoreObviously have been worn down and they were filled with some kind of a gray epoxy jb weld or something like that. And if you look inside the handle if you can see in there.
How do you fix a shaft on a pump?
0:123:10How to Repair a Drive Shaft Using Forming Techniques - YouTubeYouTubeStart of suggested clipEnd of suggested clipFirst we clean the damaged area of the shaft. We undercut the repair area and roughen the profileMoreFirst we clean the damaged area of the shaft. We undercut the repair area and roughen the profile with a grinder next between the prepared area to remove all surface contaminants.
Is spray welding strong?
High-Velocity Oxyfuel Spray Welding Gas achieves supersonic speeds while at the same time powder is injected into the flame. The process provides dense thermal spray coatings with less than 1% porosity. The result has high bond strength and fine as-sprayed surface finishes. Oxide levels are also low.
What is spray weld?
Spray welding is a term used to classify several welding procedures in the form of thermal spraying. It is an industrial activity that involves atomizing and spraying a powder or wire onto a metal surface at a high velocity with compressed gas.
Can splines be repaired?
When your splined shaft suffers damage or you notice wear and tear one option is to simply replace it with another. Alternatively, a salvaging operation can be resorted to, to save the part. Note, however, a repaired part is unlikely to preface the same strength and confidence as one that is new.
Can you repair axle splines?
One of the best features of Metalink™ polymers is their incredible compression strength. This allows repairs of spline shafts and keyways. Stripped spline shafts can be returned to service using Machinable Repair™ Compound by following this guideline.
What is a driveshaft spline?
Splines are ridges or teeth on a drive shaft that matches with grooves in a mating piece and transfer torque to it, maintaining the angular correspondence between them. For instance, a gear mounted on a shaft might use a male spline on the shaft that matches the female spline on the gear.
Why is a shaft worn out?
Shaft Wear and Damage In the mining industry, shafts can become worn or damaged due to vibration, friction and abrasive media.
How do you fix something to the shaft?
0:121:23How to attach something to a smooth stepper motor shaft - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe side there is a single hole for securing the hub to the shaft with a small screw in an allenMoreThe side there is a single hole for securing the hub to the shaft with a small screw in an allen wrench. When. You are putting the screw in you should be careful not to force it in misaligned.
What is a shaft sleeve?
Shaft sleeves are cylindrical metal tubes designed to protect pump shafts from erosion, corrosion, and wear at critical points, such as at the stuffing box.
Why does my car shaft leak?
While a careless installation or seal misapplication can be the cause of a leak, in many cases the problem is caused by a shaft that is worn because the seal has become a “grinding wheel” that cuts a groove in the shaft.
What is a repair sleeve?
What, exactly, is a repair sleeve? A standard repair sleeve is drawn from a specialized stainless steel alloy. The outer diameter of the sleeve is then finished to provide a high-quality sealing surface. The resulting sleeve finish, texture, and roughness are optimized for use with elastomeric radial lip shaft seals. In many cases, the repair sleeve actually creates a seal running surface that is often superior to that of the original shaft (Fig. 1). A typical thin-walled repair sleeve adds 0.022 in. to the nominal shaft diameter, which means the original shaft seal size can still be used. This sleeve eliminates the extra inventory and possible problems that could arise if a larger ID seal was required.
What happens when a radial lip seal is grooved?
If the seal surface on the shaft becomes grooved, a radial lip seal cannot effectively keep lubricant in and contaminants out.
Can you install two closely spaced shaft seals?
In certain applications, it may be necessary or desirable to install two closely spaced shaft seals. To accommodate this application, the outer repair sleeve’s flange can be removed, permitting the inner seal to slide over the outer sleeve and into position on the inner sleeve.
What happens if a shaft is broken in two pieces?
If the shaft is broken in two or more pieces because of fatigue cracking across most of the section, not much can be done to restore it to a useful part, except possibly in exceptional cases by special means (see example in a later paragraph). But before you throw a broken shaft in the scrap bin, investigate the failure.
What is a shaft made of?
Shafts commonly are made of hard steel. Welding procedures can affect repairs in many ways. High-alloy steel is prone to cracking when welded, unless special procedures, such as preheating, are put in place.
Why are shafts important?
Shafts are important, highly stressed mechanical elements used to transmit rotary motion from a driver unit to a driven part. Like any other component, a shaft can fail by one of a series of failure modes.
Feedback
One of my putter shafts has some pitting on it, and I want to get it the heck off! How should I go about doing this???
Feedback
I would just replace it with a new shaft. Most .370 iron shafts will fit a putter, depending on how the hosel is configured. A slight amount of heat until the epoxy loosens and you pull the old shaft and reshaft with a new iron shaft. If you need a special, bent shaft there should be some available through MALTBY or GOLFWORKS. Hope this helps.
Feedback
You might want to understand where the rust is starting from - from the outside or the inside.
