how to repair a weed eater pull cord

How to Repair the Pull Rope on a Homelite Weed Trimmer

• 1.. Unhook the Z-shaped end of the throttle cable from the weed trimmer carburetor throttle linkage with needle-nosed...
• 2.. Unscrew the starter housing retaining screws from the engine assembly with a flathead screwdriver or No. 25...
• 3.. Pull the weed trimmer starter housing apart from the engine assembly to access...

Full Answer

How do you replace a pull cord on a craftsman Weed Eater?

If you have a Craftsman weed eater, Garden Guides shares the steps for replacing this kind of pull cord, which is not all that different from the Poulan. Turn the weed eater off and remove the starter assembly cover with a screwdriver. Cut off the old string from the pulley and starter handle and discard it.

How do you replace the string on a Poulan Pro Weed Eater?

Garden Tools & Instruments explains that if you need to do a Poulan Pro weed eater pull string replacement, first make sure that the tool is turned off and cooled down. Loosen the screws that hold the starter cord cover. Pull this off and remove the cord, which should be attached. Next, pull out the whole starter cord from its pulley.

What is the difference between a weed eater and a pull cord?

What Can Go Wrong With a Pull Cord? Weed Eater is the brand name for a particular model of string trimmer, which means that while all Weed Eaters are string trimmers, not all string trimmers are Weed Eaters.

How do you replace the throttle cable on a weed trimmer?

The throttle cable bracket is held onto the starter housing assembly by one of the starter housing assemble retaining screws. Pull the weed trimmer starter housing apart from the engine assembly to access the starter rope pulley and starter components. Lift the starter housing pull rope pulley off of the engine crankshaft.

How do you fix a weed eater pull cord?

0:493:27Quick easy Weedeater pull string fix - YouTubeYouTubeStart of suggested clipEnd of suggested clipThen pull out the starter pulley and remove what's left of the old string. Then put your new stringMoreThen pull out the starter pulley and remove what's left of the old string. Then put your new string into the pulley and through the hole the old one was at then make a knot at the end of the new rope.

How do you fix a pull start that won't retract?

0:412:58HOW-TO Tighten A Limp Starter Rope That Won't Retract On A Small EngineYouTubeStart of suggested clipEnd of suggested clipI'm just going to turn counterclockwise. One turn on this one if the rope was out further I would goMoreI'm just going to turn counterclockwise. One turn on this one if the rope was out further I would go two turns counterclockwise. And with this recoil here one turn counterclockwise fix.

What makes a weed eater hard to pull?

The pull rope of a weed eater can become too tight to tug, making it difficult or impossible to start the machine. When this issue occurs, the rope is either twisted or jammed on the rope rotor, which prevents it from moving without excessive force.

What causes a pull cord to lock up?

One way the starter cord can get stuck is due to hydraulic lock, which is caused by oil getting trapped in the combustion chamber. You'll need to release the compression and the oil, so remove the spark plug and then give the cord a tug.

Why does my pull cord get stuck?

Problems With the Recoil Mechanism Sometimes the pull cord crosses over itself when rewinding, and when this happens, it can get stuck. You may be able to free it by pulling it gently to coax it out to its full length, then letting it rewind slowly.

How do you fix a pull start spring?

2:0710:26Best 3 Ways To Install A Recoil Starter Spring On A Small Engine - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe first thing you want to do here is cut the zip tie. Again make sure you're wearing your safetyMoreThe first thing you want to do here is cut the zip tie. Again make sure you're wearing your safety glasses. So now I have to remove it from the casing grab a good pair of pliers.

How do you reset the pull cord on a lawnmower?

3:005:35How to easily fix a lawnmower pull start cord - YouTubeYouTubeStart of suggested clipEnd of suggested clipYou'd have to take it back out again just wind it back up all the way and jam your screwdriver inMoreYou'd have to take it back out again just wind it back up all the way and jam your screwdriver in for the cord lined up undo your simple knot. Let it go back.

How do you fix a pull string?

2:033:54How to Replace the Pull Cord on a Small Engine by @Gettin' Junk DoneYouTubeStart of suggested clipEnd of suggested clipBut I've already replaced it you're gonna take this and spin it by hand against the spring. You keepMoreBut I've already replaced it you're gonna take this and spin it by hand against the spring. You keep spinning it over and over. Until you get to the point where you have a lot of tension.

How do you fix the pull cord on a leaf blower?

1:483:24How To Fix a Broken Leaf Blower Cord - YouTubeYouTubeStart of suggested clipEnd of suggested clipRun your new cord through the handle. Pull the bad cord out of this plastic piece push in the newMoreRun your new cord through the handle. Pull the bad cord out of this plastic piece push in the new cord tie a small tight knot in it. Pull the cord back down pull it into the handle.

How to start a weed trimmer with a pull rope?

Position the starter housing onto the weed trimmer engine so it rests flush with the engine crankcase assembly. Torque the starter housing assembly retaining screws between 30 and 50 inch-pounds with a torque screwdriver and No. 25 star-head or flat head screwdriver bit. Hook the throttle cable Z-shaped end onto the engine carburetor throttle linkage with needle-nosed pliers. Start and stop the weed trimmer engine several times to check for proper starter pull rope operation.

How to unwind a starter pull rope?

Unwind any remaining old pull rope from around the starter pull rope pulley, grabbing the knotted end from the pulley recess with needle-nosed pliers.

How to tension a pulley spring?

Pull about 10 inches of pull rope back through the starter assembly housing; form a loop with the rope and push the loop into the pulley notch. Wind the pulley clockwise two to three complete revolutions to tension the pulley rewind spring and hold it in position to prevent the rewind spring from unwinding.

How to remove rope pulley from starter?

Remove the rope pulley retaining bracket screws from the inside of the starter housing assembly with needle-nosed pliers and remove the pulley retaining bracket from the starter housing. Remove the starter pull rope pulley from the inner starter housing assembly shaft and pulley rewind spring hook -end.

What causes a starter rope to snap?

The starter pull rope on your Homelite weed trimmer is subjected to friction, fuel, oil and sunlight that wears the pull rope. Eventually, a strong pull on a worn, frayed pull rope can cause the rope to snap and wind back into the starter assembly housing. A pull rope in good condition is essential for starting ...

How to remove the starter cable bracket?

25 star-head screwdriver. Pull the throttle cable bracket free from the starter housing assembly. The throttle cable bracket is held onto the starter housing assembly by one of the starter housing assemble retaining screws.

How to tie a starter housing?

Thread the untied rope end up through the hole on the bottom of the rope handle and out through the hole at the top of the handle . Tie a figure -8 knot tightly at the end of the rope, feeding the end of the rope through both loops in the figure-8. Pull the rope tightly to seat the knotted end securely in the rope handle. Trim any excess rope from the top of the knotted end. Apply a light coat of all-purpose grease to the starter housing assembly shaft.

Where is the pull rope on a weed eater?

The pull rope on a weed eater is used to start the engine. The pull rope is located in the starter cord housing on the rear of the weed eater engine housing. Through normal use the pull rope can become worn or damaged causing it to break.

How to replace starter rope on a rotor?

Slowly release the rotor. Guide the new rope onto the rotor as it unwinds to coil the new rope in place. Replace the starter cover on the housing and secure it in place with the three Phillips head screws.

How to tie a rotor to a starter?

Pull the rotor up and off the starter post. Feed the end of the rope through the rotor and tie another single overhand knot in the end of the rope. Slide the rotor back onto the starter post. Turn the rotor side to side slightly to engage the rewind spring.

How to dispose of old rope?

Pull any old rope off the rotor in the housing. Pull the old rope through the starter handle and dispose of the old rope properly. Use the old rope as a guide to cut a new length of rope cord with a knife.

What happens if the pull cord on Poulan weed eater is broken?

Whether the pull cord on your Poulan weed eater is broken, worn out or not pulling in and out correctly, you will be faced with changing this cord. This cord is critical for getting your trimmer started, so you should always make sure it's working properly.

How to tie a pulley on a trimmer?

Tie your knot above the trimmer's starter handle at the pulley base and wind it around the pulley, leaving 10 inches, then make a loop. Pinch the bottom and work it back and forth until recoil spring hooks itself onto your pulley. Holding the starter cover, wind the pulley and loop around several times until there is enough tension. Hold the pulley, release the loop and unwind the new cord. Slowly let it rewind onto the pulley, ensuring that it is tight, and replace the starter cover.

How to change starter cord on a chevy?

Loosen the screws that hold the starter cord cover. Pull this off and remove the cord, which should be attached. Next, pull out the whole starter cord from its pulley. Now, open the plastic starter cover with the screwdriver and untie the rope that's inside the handle and discard it. Put your new cord into the access hole in which the old cord was attached, and push it through and lock the center tab down onto it.

Why won't my weed eater start?

One likely reason your weed eater won't start is because the weed eater pull cord is broken. In some cases, it may need to be replaced; if so, the procedure depends on the brand and model. If you have your weed eater's manual, that may be useful.

How to remove starter cover on Poulan?

The starter cover on most Poulan models is at the back end of the engine, near the muffler. Take off the starter cover and the starter cord should come off with it , because it's attached to the starter cover.

How to protect hands when working on power tools?

Whenever working on power tools, be sure to turn them off first and to allow them to cool down completely. Wear a pair of gloves to protect your hands.

How to set the tension on a recoil spring?

Wind the cord around the pulley all the way. Hold the cover in one hand and pull out the cord two full pulley rotations to set the tension on the recoil spring. Repeat if necessary to get the proper tension on the cord. Screw the starter cover back into place over the engine.
