The best solution is to find a shop that specializes in repairing BMW CCC units. You simply remove the CCC and ship it in for repair. Once the unit is fixed, just install it on your BMW; no need to code anything. You can find BMW CCC Repair Service offered even on eBay.
Full Answer
Can BMW software code used CCC modules?
Main dealer BMW software cannot code used modules, they can only do new stuff. I have an e60 535d CCC unit in my car & have gone through this process so I'm familiar with it. I am driving a 2004 645ci. Just had a major repair done for over $3,000 and now my CCC unit gave up.
Is there a BMW CCC CIC service in the USA?
BMW CCC CIC PROFESSIONAL REPAIR SERVICE! PROFESSIONAL BMW E60 E63 E64 E90 E92 E93 E91 E61 E87 E70 AND OTHERS CCC NAVIGATION PROFESSIONAL UNIT REPAIR SERVICE IN USA! YES, PROBABLY THE ONLY ONE FOR NOW. [rev_slider BMW_CCC]
Is there a CCC service for BMW E60 E63 E64 E92 E93 E91 E93?
PROFESSIONAL BMW E60 E63 E64 E90 E92 E93 E91 E61 E87 E70 AND OTHERS CCC NAVIGATION PROFESSIONAL UNIT REPAIR SERVICE IN USA! YES, PROBABLY THE ONLY ONE FOR NOW. [rev_slider BMW_CCC] WHAT YOU NEED TO KNOW ABOUT BMW CCC UNIT FAILURE (IN VERY VERY SHORT).
Will a CCC fit in a 2005 M5?
I ordered a used CCC off ebay that came off a 2005 M5. Seller assured that the unit is in perfect working order and it would be compatible with my car. Received it a week later. Installed myself and there was no reaction.
What is BMW CCC unit?
CCC stands for Car Communication Computer. iDrive is a collection of hardware and software which has the role of controlling the entertainment and communication modules in BMW cars produced from 2001 onwards. The BMW CCC unit is one particular model of the BMW iDrive system.
How much does it cost to fix BMW iDrive?
Basic CIC idrive with maps, voice command, and video in motion run about $2200-2500, sometimes you can swing a back up camera in that deal as well. This is part of what we do. We can do all the coding as well as supply all the parts.
How do I reset my BMW CCC?
0:071:38BMW iDrive CCC force reboot reset (E60 E90 E63 E87 X5 X6) - YouTubeYouTubeStart of suggested clipEnd of suggested clipAs you can see discs are out screen is off let's give a few more seconds. And the system will rebootMoreAs you can see discs are out screen is off let's give a few more seconds. And the system will reboot. In just a moment as you can see discs are back inside LCD screen is on.
How do I get rid of BMW drivetrain malfunction?
The immediate thing to do is stop your car at a safe place. Turn off the engine and let it sit for 5-10 mins. This will get your car to temporarily reset the drivetrain malfunction error so you can drive back home. After a few minutes restart your car and normally drive back.
What causes BMW drivetrain malfunction?
The three most common problems that can trigger the malfunction are an oil leak, a serpentine belt problem, or a coolant distribution issue. You can check the engine oil levels, monitor engine temperatures, and look for signs of smoke coming from the area.
How do I reset my BMW computer?
1:093:06How to RESET BMW ECU | Computer Hard reset | m235i 2 series - YouTubeYouTubeStart of suggested clipEnd of suggested clipPut back on the battery. Cover close the trunk. Turn on the car. Plug in our ob2.MorePut back on the battery. Cover close the trunk. Turn on the car. Plug in our ob2.
How do I factory reset my iDrive?
BMW Connected Drive. To reset your personal data and settings in your BMW with Operating System 7, select: "CAR menu" > Settings > General settings > "Reset vehicle data". In your BMW with Operating System 8, select: "Menu" > "System settings" > "Reset vehicle data".
Why is my BMW screen black?
Take it to the dealership, as you are still under warranty. Let your car sleep for 20 minutes and see if the computer reboots. The blank screen is a common problem and typically resolves itself after shutting off the car and restarting. Take it to the dealership, as you are still under warranty.
Does BMW update iDrive for free?
Easily find all upgrades Updating your BMW software via BMW ConnectedDrive is free of charge. The cost of BimmerTech's iDrive software update starts at $249.
How do I update my I drive?
Download any available updates to a USB drive. Insert the USB drive into one of your vehicle's USB ports. Navigate to the “Settings” menu on your iDrive system. Click on “Software Update” and follow the steps that appear on screen.
How do I know if my BMW needs a software update?
How will I know when an upgrade is available? Any newly available upgrade packages will be announced directly as a notification on your BMW control display or on your smartphone via the BMW app – just like when other new software is made available to your phone.
How do I update my BMW navigation system?
In vehicles that require manually updating your navigation's map data, the process is simple. The map data is loaded to a USB stick which can be plugged in to the USB port in your BMW's glove compartment. The system will automatically detect that there is a new map available to install on the iDrive.
What is BMW CCC?
In this post we are going to talk about very common issue with BMW CCC (CAR COMMUNICATION COMPUTER) NAVIGATION UNIT, these units were installed on all BMW cars starting from 2004 with E65 E66 RR exception (they use different MMIGT setup). Back in 2004 it was one of the most advanced units for those days and even now its got some impressive features:
How much foam is needed for a CCC unit?
ALWAYS, ALWAYS REMOVE COOLING FAN FROM THE BACK OF THE UNIT AND DOUBLE BOX YOUR CCC UNIT WITH MINIMUM ONE INCH FOAM PROTECTION ON EACH SIDE ESPECIALLY AROUND THE REAR CONNECTORS. WE SEE TONS OF SHIPPING DAMAGE PROBLEMS EVERY DAY!!!! PEASE DON'T SEND US YOUR FAN. YOU WILL ATTATCH IT ONCE YOU GET IT BACK.
What happens after a BMW is repaired?
AFTER REPAIR YOUR UNIT WILL BE FLASHED (UPDATED) AND CODED ACCORDING TO YOUR VIN NUMBER AND FSC WILL BE LOADED TO MAKE VOICE CONTROL FEATURE WORK (COMPLEX PROCEDURE AND BARELY ANY BMW CODER CAN DO THAT TO USED CCC UNIT), UNFORTUNATELY WE DON'T HAVE ALL FSC CODES AND SOMETIMES IT MIGHT NOT MATCH AFTER UPLOADING (IT SAYS ACCEPTED BUT WON'T WORK FOR SOME UNKNOWN REASON), SO WE DO NOT GUARANTEE VOICE COMMANDS WILL ALWAYS WORK AFTER REPAIR. SO MAKE SURE STICKER (IF PRESENT MATCHES YOUR VIN) OR ITS WAY BETTER IF YOU WRITE YOUR VIN AND YOUR NAME ON THE UNIT. PLEASE DO NOT INCLUDE NOTES IN THE BOX!!! WE DON'T HAVE TIME LOOKING FOR NOTES IN LOTS OF PACKING MATERIAL.
Does CCC unit fail?
CCC UNIT HAS FAILED IF YOU HAVE 12V PRESENT IN THE MAIN CCC SQUARE POWER CONNECTOR AND SEE PROBLEMS OR NOTHING ON THE SCREEN (CLASSIC BMW SPLASH LOGO REBOOT, BLANK SCREEN, FAN RUNNING WITH ALL BUTTONS LID UP ALL THE TIME DRAINING BATTERY) IN ALL THESE CASES YOU WILL SEE NO COMMUNICATION ERRORS IN ANY DIAGNOSTIC SCANNER. MOSTGW SOMETIMES STILL ALIVE OUT OF 5 MODULES (A0,63,3F,47,62)
Does the E60 have MPM?
E60/63/64 HAD MPM MODULE INSTALLED AND FAILURE TO MPM MODULE WILL CUT OFF POWER TO CCC UNIT. NOTE: MPM MODULE CAN BE SIMPLY BYPASSED IF CCC SOFTWARE NOT OLDER THAN 2006 VERSION. SIMPLY CONNECT 2 THICK RED WIRES TOGETHER AND SAVE 200$. MAKE SURE YOU ISOLATE IT WELL!!!!! WILL NOT CAUSE ANY ISSUES! MPM MODULE WAS DESIGNED IN 2003-2006 WHEN CCC MOSTGW COULD NOT “SLEEP” WELL CAUSING MINOR BATTERY DRAIN. AFTER 2006 NEW SOFTWARE FIXED IT AND MPM MODULE BECAME MORE OF A PROBLEM, SINCE IT GETS WATER DAMAGED IN THE TRUNK VERY OFTEN.
Is there a better CCC unit than a GLITCHY unit?
BETTER NO CCC UNIT, THAN GLITCHY ONE IN YOUR CAR. REMOVE THE FUSE AT LEAST OR DISCONNECT CCC UNIT AFTER IT FAILED. DO NOT WAIT! CCC UNIT CONTAINS MOSTGW GATEWAY INSIDE AND IT WILL BE REBOOTING NON STOP OTHER MOST UNITS IN YOUR CAR.
Is CIC better than CCC?
D) CIC IS DEFINITELY MUCH BETTER UNIT COMPARED TO CCC, BUT FOR MOST PEOPLE ITS NOT THAT IMPORTANT AND PRICE DIFFERENCE IS HUGE
What killed my CCC?
First off all the jump starting is probably what killed your CCC. There's a complex electronic set up in these cars (& indeed most modern cars). Jump starting is bound to send surges of current about the place.
Can you replace a car battery without registering it?
Secondly you cannot replace the battery in these cars without registering it. If you don't register it there are 2 potential issues: 1. The battery will not be charged correctly as registering the battery tells the car to change the charging cycle. 2. If you put a higher rated battery in to the car (or a lead acid battery instead of an AGM battery for example) again this will not charge properly, during the "registerng the battery" process you also indicate the Ah rating & type AGM/LA battery.
Is the E60 M5 CCC compatible with the E60 M5?
Then on to the replacement CCC. The e60 M5 CCC is compatible ith your car once it has been coded to your car. Even without coding it should power up & some functions should work, others not. You need to code 5 modules in order to have the CCC working completely:
Can Autologic code BMW modules?
In that order. Autologic should be able to do that but NCS Expert can definitely do that. Main dealer BMW software cannot code used modules, they can only do new stuff.
