Repairing Guides

how to repair fiberglass boats

by Taylor Sporer Published 2 years ago Updated 2 years ago

How To Repair a Fiberglass Boat

  • Cut Away the Damage. Impact damage nearly always results in some associated delamination. Tap the impact area with the...
  • Working from Inside. If the damage area is small and above the waterline, make the repair from inside the hull, if...
  • Dewax. Before grinding, always wash the area around the hole thoroughly with a dewaxing solvent. The...

Part of a video titled Fiberglass Hull Repair - YouTube
2:24
11:17
First up after opening up the void is to smooth the edges around the damaged area using a grinder.MoreFirst up after opening up the void is to smooth the edges around the damaged area using a grinder. You see how that little voice turned into this and you can see now we're down to solid laminate.

Full Answer

How do you repair a hole in a fiberglass boat?

  • First, examine the hole and look for cracks and chips extending out from the hole. ...
  • Next, take a saw and cut out the damaged area that you’ve circled with the marker.
  • Now that the holes cut out, you need to determine the thickness of the hull substrate and multiply that by 10. ...

More items...

How to fix a leak in a fiberglass boat?

sanding the boat hull Can Fiberglass Boats Be Repaired With Flex Seal? Flex Seal is hugely popular and it may even be possible to fix a minor leak onboard. Unfortunately, this is not a long-term repair solution. Flex Seal, while can be useful for minor leaks, is a temporary fix.

How to patch fiberglass boat?

  • In case breaks were uncovered with a V formed scrubber, complete the maintenance as trails setting up the harmed region as depicted previously:
  • Quill the edges with the scrubber or with 100-coarseness sandpaper and brush the surface liberated from dust and free material.
  • Wet out the breaks with a 105 Resin/hardener combination. ...

More items...

How to use fiberglass for repairs?

Fiberglass is rather easy to repair. Here's how. Drill a tiny hole at each end of the crack. This will stop the crack from extending any further. Examine the crack. If it's a hairline crack, use an electric or hand held rotary blade to widen the crack just a bit. This will make it possible to fill the crack with epoxy resin.


How do you repair a fiberglass boat hull from the outside?

Step-by-Step Guide To Repair Fiberglass Boat Hull From the OutsideStep 1: Grind around the hole. ... Step 2: Clean the damaged area. ... Step 3: Back up the hole. ... Step 4: Prepare the patch. ... Step 6: Apply the layers of roving. ... Step 7: Apply the fiberglass cloth. ... Step 8: Allow the patch to dry and remove irregularities.

How do you repair fiberglass damage on a boat?

Fill any deep gouges and spend your time sanding out scratches while the filler sets up. Apply gel coat to the filled gouges and finish to the scratches and then final-sand the filled gouges. Buff all the repaired areas and then the rest of the boat. Apply any graphics to finish up.

How do you repair a deep gouge in a fiberglass boat?

0:392:51How to Repair Deep Cracks in Fiberglass Boats - YouTubeYouTubeStart of suggested clipEnd of suggested clipUsing the disposable brush saturate it with epoxy. One at a time apply and saturate theMoreUsing the disposable brush saturate it with epoxy. One at a time apply and saturate the progressively smaller pieces of fiberglass.

How much does it cost to patch a fiberglass boat?

“ However, going to a boat repair specialist comes with astronomical fees of up to $3,000. But here's the surprising truth most boat experts won't tell you: most repairs really aren't that expensive. Patching a fiberglass boat can cost as little as $500 or less if you're not afraid of some elbow grease.

Can You Use Flex Seal on a fiberglass boat?

Flex seal is advertised to adhere to fiberglass and aluminum, so you should have no problem with it sticking to your boat.

Can you patch fiberglass boat?

0:4715:14Fiberglass Hull Repair how to easily fix a thru hull hole - YouTubeYouTubeStart of suggested clipEnd of suggested clipIn addition i like to use acetone to to prep the work area and degrease it so that the fiberglassMoreIn addition i like to use acetone to to prep the work area and degrease it so that the fiberglass resin adheres nicely to the to the fiberglass. And lastly we're going to use a angle grinder.

How do you repair a chip in a fiberglass boat hull?

0:043:27XS Ribs: How to do a Fibreglass / Gell Coat Repair of a Chip or ... - YouTubeYouTubeStart of suggested clipEnd of suggested clipDifficult. So make sure the hole is all clean and dry mix up your resin a lot of people don't mix upMoreDifficult. So make sure the hole is all clean and dry mix up your resin a lot of people don't mix up enough resin.

Can a fiberglass boat hull be repaired?

However, the repairability of fiberglass is one of its best characteristics. The most horrifying hole in a fiberglass hull is quickly healed with a bit of glass fabric, a supply of resin, and equal parts skill and care. And the repair is less patch than graft — a new piece of skin indistinguishable from the old.

How do you fix deep gouges in gelcoat?

Begin by sanding around the area and the scratch with 320-grit paper. Again, be cautious not to remove too much material. After sanding, use a Dremel tool to clean out the gouge a bit, then feather the edges of the scratch with 180-grit. This helps the gelcoat blend in and helps hide the edges of the filled scratch.

Can fiberglass be repaired?

In comparison to traditional building materials, Fibreglass composite materials are generally easier to repair. It is important to note that once the original fibreglass laminate is damaged, any repairs to the original are considered as secondary bonds.

How do you fix a gelcoat chip on a boat?

0:355:22How To Repair DIY Chipped Gel Coat fiberglas Boat : Marine - YouTubeYouTubeStart of suggested clipEnd of suggested clipBut there's some missing chunks that I'm going to fill with the gelcoat repair kit gelcoat is simplyMoreBut there's some missing chunks that I'm going to fill with the gelcoat repair kit gelcoat is simply just fiberglass resin that's tinted. So you can buy some inexpensive kits that are easy to to

How to fix deep scratches on boat?

To fix gouges and deep scratches, you’ll need “chop” (powdered fiberglass) filler, gel coat and gel coat reducer. Jot down your boat’s model and serial numbers and contact the manufacturer to order gel coat (about $100 per qt.) to match your boat’s color.

What is the gel coat on a fiberglass boat?

All fiberglass boats have a thick structural core of fiberglass strands impregnated with polyester resin. But the part you actually see is the gel coat. That’s the thin layer of pigmented resin that gives the boat its sheen and color. Most light scratches are in the gel coat layer.

How to mix gel coat?

Mixing gel coat is a messy and stinky process—so wear chemical-resistant gloves, safety goggles and a respirator. Start with a small amount of gel coat and stir in the chop and hardener to make a putty that’s the consistency of peanut butter (Photo 3).

What is a repair pro?

A repair pro shows you how to make invisible fixes for scuffs, dents and scratches in fiberglass boats and other fiberglass items. You'll save a ton of money if you're patient and use the proper tools.

How long does it take for resin to harden?

Once you add the hardener, you’ve only got a 10- to 20-minute “open” time, so mix small batches and work on one gouge at a time. Thorough mixing is critical to proper curing. Spend a full minute stirring. If you don’t, you’ll end up with patches of sticky resin that can take days to harden.

Can you spray gel coat on fiberglass?

Spraying gel coat isn’t like spraying paint. It splatters on and has to be sanded and buffed to get to a smooth gloss. So don’t be disappointed that the finish isn’t paint-like right away during your fiberglass boat repair.

What happens if a boat hull is flat?

If the hull is flat or curving in only one direction in the damage area, the backer will assume the correct curve. If the hull is spherical, i.e. curving in two directions, acrylic screwed to the hull can sometimes be coaxed into the correct shape if warmed with a heat gun (before applying the mold release).

How many layers of fiberglass to make a hole?

Unless you have reason to follow a different schedule, begin with two layers of 1 1/2-ounce mat, then alternate mat and 6-ounce cloth. The number of laminates will be determined by the thickness of the hull; you will roughly need one layer for every 1/32 inch.

Why is resin laid up?

During the lay-up process, because each layer is applied before the previous one fully cures, each application of resin links chemically with the previous one to form a solid structure--as though all the layers were saturated at once.

How to make a plastic backer?

Wax this backer, then spritz it with polyvinyl alcohol (PVA) mold release. Screw or tape the backer to the outer surface.

How to get rid of dust on a sanded surface?

Tilt the sander so that only one side of the disk is touching the surface and the dust is thrown away from you. After you brush away the dust and wipe the area with an acetone-dampened rag, the sanded surface should have a uniform dull look.

Can you use epoxy for above the waterline repairs?

For above-the-waterline repairs you can use either polyester or vinylester resin. Of course, for an even stronger repair you can also use epoxy, but not if the surface of the repair will be gelcoat. (You should use epoxy for underwater repairs.)

Is fiberglass lay up more durable than epoxy?

Fiberglass lay-up is nothing more than layers of glass fabric saturated with polyester (or epoxy) resin, yet most boatowners imagine a self-applied repair as only slightly more durable than a wet Band-Aid. This is a false concern.

What are the two types of scratches on fiberglass?

There are two essential types of scratches you’ll encounter. with fiberglass: A light, surface-level scratch. A deeper, penetrating scratch. In the case of the surface-level scratch, your mission. should be to repair the gel coat. Using a polishing compound like.

What is gel coat on fiberglass?

A gel coat is essentially a. finish on the fiberglass. It’s very thin, but it can help protect the. fiberglass and the boat itself from the marine environment. If your fiberglass. gets scratched, that means there’s been damage to the gel coat as well. repair the gel coat itself.

How to restore shine to fiberglass boat?

To restore shine to a fiberglass boat, it’s necessary to remove the oxidized portion of the gelcoat, and return the outer surface to the glassy reflective finish it once had. It’s necessary to polish, or compound first and then polish the boat to restore the finish. Polish is a mild abrasive that gently removes the very topmost surface ...

Why is my fiberglass boat dull?

This is caused by the gelcoat oxidizing and suffering water damage.

Why wax a boat?

Wax provides a protective layer over the gelcoat that helps prevent further oxidation. If the boat isn’t waxed after it’s polished, the gelcoat will quickly oxidize again, and you’ll be forced to compound and/or polish it once more. Applying two or more coats of wax offers maximum protection to the gelcoat.

What is the outer layer of a fiberglass boat called?

Fiberglass boats have a protective outer layer called gelcoat. The gelcoat plays no structural role in the construction of a boat, but it does form a protective barrier between the fiberglass and the elements, in particular UV rays and water.

Why do boats need gelcoat?

Over time, exposure to harsh UV rays and moisture causes the gelcoat to oxidize, a chemical reaction that breaks down the surface .

What happens when gelcoat oxidizes?

Oxidation leaves gelcoat feeling rough to the touch, and gives it that slightly opaque, chalky look. When gelcoat oxidizes, it enables water to penetrate the surface. The water works into the compromised surface to form tiny pits, and eventually blisters and bubbles. The sooner you restore your fiberglass boat’s finish, the better, ...
