- Unscrew the cylinder from the body of the grease gun and remove the old grease cartridge
- Open a new lubricant cartridge and insert it into the tube. ...
- Screw the refilled tube back onto the body of the grease gun until tight, then back it off one full turn
- Push the plunger back in and re-tighten the threaded cylinder onto the body of the grease gun
How to refill a grease gun the easy way?
Method 2 of 2: Refilling a Gun with a Grease Bucket Download Article PRO
- Unscrew the canister from the top of your grease gun. Use both hands to rotate the main section, or canister, counterclockwise from the head of your tool.
- Rotate the bottom cap to remove it from the canister. Examine the canister to find a sturdy cap attached to the bottom of the tool.
- Slide the piston out of the main canister. ...
How do you load a grease gun?
You should get the plunger rod pulled out of the grease gun, unscrew the head, load in the cartridge, screen back the head of the grease gun, and push back the plunger rod. That is the easiest way of loading the grease gun, and to bleed it, you need to keep pumping the grease gun until grease starts coming out of the nozzle.
How to use a grease gun properly?
Useful Hacks:
- The grease guns will load more efficiently if you have bulk grease in a large container.
- You need to make sure the handle is pressed fully into the barrel to avoid any risk of grease being sucked accidentally during the process.
- Always clean the tip of the grease gun when there is excessive grease every time after you use it. ...
How to load and Prime any grease gun?
- At the time of turning on the barrel with loading new tube of grease, you will need to back it off full turn in order to permit a little air ...
- If slackening barrel doesn’t continue, then you can use the air bleeder control device. ...
- Furthermore, you can try to pertain manual stress by high pressure, if you cannot prime your gun.

How do you fix a grease gun?
2:494:44My grease gun does not dispense, What do I do! - Lincoln Quick TipsYouTubeStart of suggested clipEnd of suggested clipSituation. Once grease gun is primed reattach the hose or extension with the coupler removed. AgainMoreSituation. Once grease gun is primed reattach the hose or extension with the coupler removed. Again cycle the unit to purge the hose or rigid extension of contaminants.
Why does my grease gun stop working?
The most common cause is an air lock. This can be fixed by continuously pumping to see if the air will pump out. Secondly by unscrewing the barrel one turn and continuously pumping, then tightening the barrel when the grease pumps.
How do you disassemble a grease gun?
0:042:21How to replace grease in a grease gun - YouTubeYouTubeStart of suggested clipEnd of suggested clipSecond step unscrew the top of the grease gun off of the canister third step two fingers pull yourMoreSecond step unscrew the top of the grease gun off of the canister third step two fingers pull your old grease tube out recommend you do not buy this brand does not last long.
How do you bleed air from a grease gun?
1:053:47How to Fill and Bleed a Grease Gun | KINCROME Tool Talk - YouTubeYouTubeStart of suggested clipEnd of suggested clipStep two it pays to know how the grease gun actually works start by unscrewing the gun head from theMoreStep two it pays to know how the grease gun actually works start by unscrewing the gun head from the main barrel turn the head upside down you can see that this one hasn't been used.
Why is grease not coming out of grease?
0:080:45How to purge air from Grease Gun - YouTubeYouTubeStart of suggested clipEnd of suggested clipNothing is coming out to fix this problem. Simply turn anti-clockwise two or three turns. This willMoreNothing is coming out to fix this problem. Simply turn anti-clockwise two or three turns. This will release the air to the top of the tube pump.
How do I know if my grease gun is working?
1:342:17How To Use Grease Guns - YouTubeYouTubeStart of suggested clipEnd of suggested clipContinue. This until grease starts flowing again on the smaller 120 mil gun just loosen theMoreContinue. This until grease starts flowing again on the smaller 120 mil gun just loosen the cartridge tuber turn or two this should release the air then pump until the grease comes out and retighten.
How do you put a grease gun coupler back together?
0:553:53Getting A Secure Fit With Your Grease Gun - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd slide that thing on it and they're having to hold it on there and if they get the pumping itsMoreAnd slide that thing on it and they're having to hold it on there and if they get the pumping its popping around and it'll slide off.
How do you replace a small grease gun cartridge?
0:002:30How to change small grease gun cartridge - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd then unscrew the hook three down the top little cleaner you can see on our new one the torrentsMoreAnd then unscrew the hook three down the top little cleaner you can see on our new one the torrents going to go in. Let's point me there's no one things a little afternoon.
How do you remove a grease gun tube?
0:172:26How to Change a Grease Tube Cartridge - YouTubeYouTubeStart of suggested clipEnd of suggested clipUntil it's off and we're gonna reach in pull out our old grease. We're gonna take our new grease.MoreUntil it's off and we're gonna reach in pull out our old grease. We're gonna take our new grease. Then we're just gonna take the top. Off pull that off you can see the grease in there.
Why does grease gun get stuck on ZERK?
Grease guns get stuck on fittings due to clogged zerk fittings which don't let the grease pass through and cause a pressure build up that prevents them from releasing. So to get it unstuck unscrews the hose or hardline from the gun which will release the pressure and allow it to come off.
How do you prime a pneumatic grease gun?
Pull the t-pull so the follower rod comes back out of the barrel. While pulling straight down, twist it 1/4-1/2 turn. You'll feel it pop down and lock in place. you can now push up on the t-pull and it will be applying pressure to the follower plate and pushing the grease up.
How to tell if a grease gun is working?
When you depress the pressure out of the grease gun, do so slowly, and you’ll be able to see if the piston is moving correctly or not.
Why is my grease gun so stiff?
Some people have mentioned that they think it’s because the plunger is too large for the grease gun to work properly. Look when you get a new grease gun, it can be a little stiff at first, but just keep at it, perhaps push a little harder, and it will become easier to use.
How to avoid air bubbles from grease gun?
To avoid getting air bubbles, make sure to store your grease gun hung on your wall correctly.
How to get air out of grease gun?
Turn the base of your grease gun anti-clockwise, this will help you release the air as easily as possible. You shouldn’t need to turn the base more than two to three times. Now, continually pump the grease gun while you are rotating the base, this will allow the trapped air to flow out.
How to seal grease gun?
When you start to see grease come out of the nozzle, you can twist the base clockwise again to seal your grease gun up
What happens if you damage a grease gun?
If you do accidentally damage yours, this will affect whether or not grease can come out of your grease guns nozzle, you may need to replace your grease gun.
Can a grease gun be fixed?
Fortunately, the majority of these issues that you might face can be easily fixed. So if your grease gun is not working properly , then you’ve come to the right place.
What is problem 5 on a grease gun?
The damage may have been caused by so many things like an accident with the grease gun.
Why does my grease gun stop working?
The spring may have come loose and then not give the chamber adequate pressure to power the chamber with the coupler.
How to change the base of a grease gun?
Step one: Change the base of the grease gun by turning it anti-clockwise. The goal of this step is to allow as much air to go out as possible. Do this by twitching the base two to three times at the most.
Can a loose gun spring be fixed?
The spring may have come loose and then not give the chamber adequate pressure to power the chamber with the coupler. This problem can easily be fixed with the help of a new gun spring. It may come as an inconvenience if it interrupts a job’s process, but it should fix the problem.
Can air be trapped in a gun?
Air may be trapped in the gun.
How to get rid of air bubbles in grease gun?
Use 1 hand to hold the grease gun in place, and another to reinsert the plunger into the canister. Apply a slow, steady pressure to the plunger as you stick it back in the grease gun so the grease won’t have any air bubbles.
How to use a plunger to suck grease?
Hold the canister in 1 hand while using your opposite hand to hold the base of the plunger. Place the tip of the canister about 2 in (5.1 cm) into an open bucket of grease, then pull slowly on the plunger. Extend the plunger to its full length to create a suction force, which sucks grease into the tool.
How to get grease gun to work?
Extend the plunger from the back of the gun and secure it in place. Wrap your pointer and middle finger beneath the grease gun’s handle and pull upwards. Remove the plunger completely , then listen for a sound of air releasing, which means that it’s fully extended.
How to remove grease from a grease gun?
1. Unscrew the main canister from the head of your grease gun. Rotate the grease gun’s base, which looks like a large cylindrical canister, counterclockwise. Continue twisting the canister until you’ve detached it from the head and nozzle of the gun. The top portion of the grease gun is often referred to as the head.
How to change grease gun cartridge?
Twist the cap off the bottom of the new cartridge. 1 The cartridge is always installed in the grease gun with the cap side down. 2 You might need to apply a lot of force to twist off the cap completely.
How to reattach grease gun head?
Reconnect the grease gun head partially to the filled canister. Center the top portion of the grease gun on top of the canister, then rotate it clockwise several times to begin reattaching it. Stop rotating once both components are partially secured together.
How to get piston out of grease gun?
Slide the piston out of the main canister. Use 1 hand to slowly pull the piston and its accompanying spring out of the grease gun. Try to keep the tool as level as possible while you work.
