how to repair lawn mower deck

by Jarrod West Published 3 years ago Updated 2 years ago

How to Fix a Rusted Lawn Mower Deck

  • Safety First. Before you start doing any work on your lawn mower, make sure you pull the spark plug to prevent it from starting accidentally.
  • Get Rid of Surface Dirt. Remove any surface dirt or stuck on grass from the mower deck before you start working on the rust. ...
  • Break Out a Wire Brush. Make sure you have the mower over a tarp or in an area that’s easy to sweep, and then break out a wire brush to ...
  • Remove Oil and Grease. Use paint thinner to remove any oil or grease on the deck. This can easily be applied with a rag or washcloth.
  • Apply a Rust Converter and Paint. Once the surface is completely dry, apply a rust converter. ...

Part of a video titled Mower Deck Repair: Fab and Welding - YouTube
4:04
13:34
If I ever need a short piece of metal or whatever they'll cut me off a piece and sell it to me ifMoreIf I ever need a short piece of metal or whatever they'll cut me off a piece and sell it to me if they got it well they actually just went and using their sheer. Went out and cut some plate material.

Full Answer

How do you keep your lawn mower deck from rusting?

Get all of the grass out of the mower deck before storing it and DON’T USE SHARP TOOLS TO CLEAN THE UNDERSIDE OF THE DECK! (screwdrivers, putty knives, etc.) This just scratches the paint and allows more rust to form. Also, once a year or so when you have it really clean underneath, get under there and spray any bare metal spots with spray paint.

How do you remove the deck from a riding lawn mower?

The most common way to remove the deck from a mower is to place it on its side, then remove all bolts holding it in place by turning them counterclockwise with an appropriate wrench.

Should I repair or replace my 42″ Dixon riding mower deck?

This 42″ Dixon riding mower deck is pretty ate up. Mostly due to rot and age. However it does seem (mostly) structurally sound. There is little to no rust around the bearings or around where the blades themselves are which is good for or purposes of repairing. One consideration when looking at repair vs replace is if the part is even available.

What is the deck of a lawn mower called?

The deck of a lawn mower is the surface that the blades of grass and dirt rest on. The deck is also called the cutting surface or bed. To level your lawn mower deck, you should first start by removing any debris from the deck.


How do I fix my mower deck without welding?

2:0717:18How To Repair a Mower Deck Without Welding - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd I don't have a welder. I'm just gonna pop rivet. I'm pre-drill the holes in this pop rivet aMoreAnd I don't have a welder. I'm just gonna pop rivet. I'm pre-drill the holes in this pop rivet a piece on. And just see how long it gets me you know the deck.

How do you repair a rusty lawnmower deck?

How to Repair a Rusted Lawn Mower Deck (Step by Step)Prepare a well-ventilated workspace.Position the mower so it can be worked on.Clean down rusted area.Knock down damaged metalwork.Grind/file back rusted surfaces.Apply rust-inhibiting paint.Cut the glass matting.Mix & apply activated resin.More items...

How do you repair a cracked mower deck?

5:2213:33Cracked Mower deck repair on the cheap, no welding. - YouTubeYouTubeStart of suggested clipEnd of suggested clipAs you can see there's plenty of distance between the repair and the tip of the lawnmower blade. YouMoreAs you can see there's plenty of distance between the repair and the tip of the lawnmower blade. You don't want to interfere with the blade.

Can a mower deck be welded?

0:3315:45Mower Deck Welding Repair - YouTubeYouTubeStart of suggested clipEnd of suggested clipSo hope he doesn't find it with his lawnmower when we get done fixing this thing. But that's not theMoreSo hope he doesn't find it with his lawnmower when we get done fixing this thing. But that's not the difficult part of this repair not that this is a difficult repair if you have the right tools once

Can a mower deck be replaced?

Replacing the Mower Deck Once again, make sure the height of cut lever is in its lowest position. Slide the deck under the machine and push it rearward to replace the belt on the engine pulley. Then move the deck forward until it's in position to lift the back end and re-hang it on the rear support bracket.

Are Craftsman 42 inch mower decks interchangeable?

Lawnmower decks are largely interchangeable. Engines will swap without issue. However, blades and drive systems may differ.

How do you weld a rusty mower deck?

0:006:01welding (lawn mower deck repair) - YouTubeYouTubeStart of suggested clipEnd of suggested clipIt. First remove whatever parts are in your way. So you can gain access like this wheel. Using anMoreIt. First remove whatever parts are in your way. So you can gain access like this wheel. Using an angle grinder either a solid disc or a flap disc your.

What are lawn mower decks made of?

There are three main materials used in the manufacture of lawnmower decks. These are - Plastic*, Steel and Aluminum alloy. Plastic – generally cheaper so often found on budget, entry-level machines, (though you may find plastic decks on some premium models, some Honda mowers for example).

Does welding melt metal?

As opposed to brazing and soldering, which do not melt the base metal, welding is a high heat process which melts the base material. Typically with the addition of a filler material.

How do you weld a rusty mower deck?

0:006:01welding (lawn mower deck repair) - YouTubeYouTubeStart of suggested clipEnd of suggested clipIt. First remove whatever parts are in your way. So you can gain access like this wheel. Using anMoreIt. First remove whatever parts are in your way. So you can gain access like this wheel. Using an angle grinder either a solid disc or a flap disc your.

How do you clean a rusty lawn mower?

0:051:25How to Remove Rust from Lawn Mower - YouTubeYouTubeStart of suggested clipEnd of suggested clipBut just run that steel wool over it until it smooths it down you can also use a piece of real fineMoreBut just run that steel wool over it until it smooths it down you can also use a piece of real fine sandpaper if it's really bad just to get through some of that rust and down to the metal.

How do you repair rust on sheet metal?

0:2016:15HOW TO REPAIR RUST HOLES IN BODY PANELS, SHEET METAL ...YouTubeStart of suggested clipEnd of suggested clipThe new piece into the old piece which is where you lay a piece in completely flush weld all the wayMoreThe new piece into the old piece which is where you lay a piece in completely flush weld all the way around. And then sand off the world around the outside.

How do you remove rust from a lawn mower blade?

Use the ratchet to remove the bolt and the blade. If the bolt will not turn, spray a lubricant like WD-40 on the bolt to loosen up any rust. Hold the blade with one hand and loosen the bolt with the other. You can also use a block of wood and a clamp to keep the blade from turning.

Cutting out the patches

I decided that I was NOT going to bother with trimming the holes perfectly and inserting filler plates. Due to how thin the metal was in some spots, I decided to just cut the patches with plenty of overlap so I was able to weld where there was good thick steel.

Bending the filler plates

I totally forgot to take pictures of bending these. I DID however take a time lapse video below of the entire process which includes me bending the plates, so keep reading.

Welding the filler plates

The welding itself was mostly uneventful. My welder has 5 settings and I had it on 1 to minimize burning through. You will have to do some testing to figure out what settings work for you and your project. Here are some notes on the difficult areas though:

Time lapse video of the repair

Here is a quick 2 minute time lapse of the repair start to finish. I thought it was kind of cool and got some video of using the bender on the patches. Take a look and like/subscribe!

A word about quality standards

I am all about doing the best work possible, but I am also conscious about the intended purpose vs the time invested. In this case, the lawnmower is given a new lease on life and I only invested a couple of hours. Could I have spent more time on it and made it beautiful? probably but there would be no advantage in doing so.

Conclusion

We have become a disposable society, but if you have the right tools and a little bit of gumption you can really make things last. It is also fun to find good deals when others don’t feel like fixing things and sell them cheap. Hope this is helpful to you.
