The repair of modern valve bodies usually includes the sequence of following procedures: - collection of and analysis of computer data (fault codes), diagnostics (vacuum testing) - valve body teardown/removal - valve body cleaning/washing
Full Answer
How to remove automatic transmission valve body?
Toyota Corolla Repair Manual: Transmission valve body assy (atm)
- Remove engine under cover lh
- Drain automatic transaxle fluid remove the drain plug, gasket and drain atf. install a new gasket and drain plug. ...
- Remove automatic transaxle oil pan sub–assy Remove the 18 bolts, oil pan and gasket. ...
- Remove valve body oil strainer assy Remove the 3 bolts and oil strainer. ...
How to replace your transmission valve body V2?
What are the Warning Signs of a Bad Valve Body?
- Trouble shifting into lower gear
- gears slipping suddenly without warning
- downshifting or upshifting on its own
- slow shifting or pausing when you try to accelerate or decelerate
- RPMs increase when upshifting
- audible banging sound when the vehicle changes gears
How does the valve body work in a transmission?
What is a Transmission Valve Body?
- The Valve Body. The valve body acts as the control center of the automatic transmission. ...
- Transmission Solenoids. A solenoid is basically an electro-hydraulic switch that controls the valves in the valve body. ...
- Fixing the Problem. ...
- Transmission Rebuild & Repair Experts. ...
Do I have manual valve body?
You must line up the manual valve with the detent lever of your transmission. The OEM manual valve is used with this valve body kit. The manual valve has an opening that the detent will fit into. The detent lever moves the manual valve when you manually shift the vehicle. You are now ready to install the manual valve body. Install gasket, separator plate, gasket, and BTE manual valve body.

Can a valve body be repaired?
If your transmission's valve body has become worn or damaged, this will usually require a proper rebuild of the transmission to repair. Occasionally this will involve simply rebuilding or replacing the valve body, but this is usually a shortcut that will lead to more problems.
How do I know if my transmission valve body is bad?
What are the Warning Signs of a Bad Valve Body?Trouble shifting into lower gear.gears slipping suddenly without warning.downshifting or upshifting on its own.slow shifting or pausing when you try to accelerate or decelerate.RPMs increase when upshifting.audible banging sound when the vehicle changes gears.More items...
What happens when a transmission valve body goes bad?
One of the most common symptoms of a failing transmission valve body is a delay in shifting or harsh shifting. Usually called garage shifts, it's when there is a harsh shift from park to drive or drive to reverse. Try to limit the number of times you are in that situation, even if it means backing into the garage.
Can you drive with a bad transmission valve body?
Can you drive with a bad transmission valve body? You should not—we emphasize, not—drive with a faulty transmission valve body for too long. A minor problem with your transmission valve body may develop into a major issue with your whole transmission over time.
What causes transmission valve body failure?
Reasons for Transmission Valve Body Failure One reason for failure is a poor oil pressure. Also, without a high enough pressure, certain valves won't operate correctly, causing a chain reaction and poor functioning gearbox. This low pressure can be caused by low levels of transmission fluid or leaks.
How do you test a transmission valve body?
1:377:12Valve Body Testing Machine VBTM-K - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe first mode the test Selenites mode checks the valve bodied wiring connections while performingMoreThe first mode the test Selenites mode checks the valve bodied wiring connections while performing the test the controller checks on the current value on solenoids and lets you know immediately.
How much does it cost to fix a valve body?
The average valve body replacement cost is between $400 and $1500, depending on the car model and labor costs. A valve body costs $200 to $1000$ for the part and $200 to 500 in labor cost.
Will a bad valve body throw a code?
Since the transmission valve body is responsible for so many functions of the transmission, many transmission related DTC codes can pop up. These may include P0715, P0751, P0783, P0829, P2707, among others. It is easy to ignore these kinds of symptoms in the beginning because they may not be so bad.
Where is a transmission valve body located?
0:092:50Technology Explained: Valve Bodies & How TCI® Builds Them BetterYouTubeStart of suggested clipEnd of suggested clipThe valve body is located on the bottom side of the transmission a fluid pan such as TC i--'s maxMoreThe valve body is located on the bottom side of the transmission a fluid pan such as TC i--'s max cool deep aluminum pan covers the valve body assembly. It contains a maze of channels.
How long does it take to replace a transmission valve body?
Since replacing a transmission valve body can take anywhere from 2 to 4 hours to finish, you must figure the hourly rate of a mechanic is between $60 to $100. This means the least you will pay for labor is $120 and the most you will pay is $400.
Why won't my car move when I put it in drive or reverse?
If the oil level is full and the transmission does not move in drive or reverse, then put the transmission in low. If the vehicle moves in low, then the transmission burned the clutches and needs overhauled.
What are symptoms of a bad transmission solenoid?
When to book a transmission service: 7 signs of solenoid failureDelayed or unpredictable gear shifting. ... Skipping gears. ... Getting stuck in certain gears. ... Vehicle sluggishness. ... Inability to downshift/upshift. ... Check Engine light / transmission warning light. ... Engine continues to rev when applying the brakes.
Will a bad valve body throw a code?
Since the transmission valve body is responsible for so many functions of the transmission, many transmission related DTC codes can pop up. These may include P0715, P0751, P0783, P0829, P2707, among others. It is easy to ignore these kinds of symptoms in the beginning because they may not be so bad.
What are symptoms of a bad transmission solenoid?
When to book a transmission service: 7 signs of solenoid failureDelayed or unpredictable gear shifting. ... Skipping gears. ... Getting stuck in certain gears. ... Vehicle sluggishness. ... Inability to downshift/upshift. ... Check Engine light / transmission warning light. ... Engine continues to rev when applying the brakes.
How much does it cost to replace a valve body?
The average valve body replacement cost is between $400 and $1500, depending on the car model and labor costs. A valve body costs $200 to $1000$ for the part and $200 to 500 in labor cost.
What are the symptoms of a shift solenoid?
The most common symptom of a bad shift solenoid is shifting issues with your automatic transmission....The main symptoms of a bad or failing shift solenoid include:Check Engine Light.Transmission Warning Light.Shifting delays.Skipping gears.Stuck in gear.Downshift or Upshift Issues.Limp mode.
What to do if valve body does not have spring?
If your valve body does not have a spring, check the new valve body for the presence of a spring and remove if required. MAKE SURE YOUR NEW VALVE BODY’S CONFIGURATION MATCHES THE OLD VALVE BODY. BE CAREFUL NOT TO DAMAGE COVER GASKET. If valve pops up when cover and gasket are removed, a spring is present.
How to install a valve assembly?
DO NOT INSTALL IN WRONG POSITION. EACH ASSEMBLY IS DIFFERENT. Install valve assembly brackets along with 10mm and 8mm bolts. DO NOT OVER-TIGHTEN. Your replacement valve body is ready to install.
What bolts are removed with sensor retainer?
Note that bolt 1 was removed with the sensor retainer. When removing bolt 7 be sure to catch the cover and gasket. They will be reused during installation. You will need to support the valve body while removing bolts 8 and 9.
What happens if a valve pops up?
If valve pops up when cover and gasket are removed, a spring is present. IF VALVE APPEARS TO HAVE NO SPRING, MAKE SURE IT IS NOT STUCK.
How to disconnect lower solenoids?
Begin by disconnecting the 5 lower solenoids using a small flathead screwdriver to push in the tab near the base of each while lightly pulling the connector out.
How to remove the left wheel splash guard?
Remove theleft wheel splash guard by carefully pry the center of each clip and remove the entire clip. DO NOT PULL THE CENTER COMPLETELY OUT OF CLIPS.
What are the different types of valve body bolts?
Take time to identify the valve body bolts. There are three types: 2 Short, 3 Long, and 4 Medium. All are 10mm.
How does a valve body work?
The modern valve body is controlled by means of electrical signals from TCM (transmission control module) and distributes/directs the oil pressure from the oil pump to an appropriate clutch drum to shift gears and lock the torque converter. Valves that operate in the valve body serve different purposes and their names reflect what they do. For example, the valve body has a 2-3 shift valve which is responsible for up shifting from 2-nd gear to 3-rd gear. And if there’s going to be a downshift from the 3-rd to the 2-nd gear, then the 3-2 shift valve would perform this operation.
How to tell if a valve body is failing?
Typical symptoms of the valve body failure in automatic transmissions occur in the form of increased vibration and scraping noise when shifting gears. In many cases issues with the valve body become evident because of jolts, kicks and slipping between gears.
What is an ATF valve?
These valves are considered to be a two-position control device which can be in On (Open) and Off (Closed) operational conditions. ATF flows via these valves to spool-type control valves, which open or close channels intended for transfer of ATF to actuators of gear shifting mechanisms. In modern electronic automobiles, they’re controlled by solenoids, while in older models, they’re driven by hydraulic pressure. Control valves open in accordance with the current passing through their windings and change the pressure of ATF in the mainline. These valves are divided into the following subtypes:
What is the primary regulator valve?
The primary regulator valve, which specifies the volume of ATF transmitted from the gearbox pump.
What valve controls throttle pressure?
The cut-back valve, which controls throttle pressure as the car changes speeds, ensuring that the pump always provides the right volume of ATF
What is a valve body?
All automatic transmissions are equipped with a valve body, which plays the role of the main control unit. Basically, the valve body is a hydraulic “controller” (also called as a “transmission brain”) consisting of valves, solenoids, sensors batteries and attached to them are passages and channels, ...
What is downshift timing valve?
The downshift timing valve, which hinders random downshifting from overdrive.
How much does it cost to replace a transmission valve body?
On average, a transmission valve body assembly will cost you anywhere from $200 to $500. Then you must consider the labor costs which may be quite extensive. Since replacing a transmission valve body can take anywhere from 2 to 4 hours to finish, you must figure the hourly rate of a mechanic is between $60 to $100.
What is valve body?
Not to be confused with the intake and exhaust valves in your engine, the valve body is an assembly inside an automatic or CVT transmission that routes automatic transmission fluid (ATF) throughout the transmission. The transmission fluid is sent to the right place at the right time by using hydraulic circuits, ...
What happens if a transmission is not able to downshift?
If the transmission is not able to downshift, then hydraulic fluid may not be entering or navigating the transmission valve body properly. Once this happens, the gears cannot be pressurized properly which degrades the performance of the vehicle.
How does transmission fluid work?
The transmission fluid is sent to the right place at the right time by using hydraulic circuits, controlled by a system of valves and solenoids that direct the flow. Depending on the position of each solenoid, each hydraulic circuit activates a different function of the transmission. Some examples of these functions are gear selection, ...
What happens if a TCM solenoids fail?
If one of these solenoids were to fail, you may find yourself locked out of certain gears, or you may be unable to shift at all.
Why does it take so long to shift gears?
Does it take a long time to shift gears from reverse or drive (or the other way around)? Sometimes a malfunctioning transmission valve body will delay the fluid flow, causing delays in gear shifts.
Why does my shifter slip out of gear?
Your shifter should never slip out of gear if your transmission valve body is fully functional.
What is a valve body?
The valve body is a part of all automatic transmissions that acts as the main control center of the system. When a failing valve body causes symptoms and/or failures like noise during gear shifts, slippage, delays, and difficulty reversing, a driver is left with no choice but to fix or replace the part. The choice then falls on your shop, so ...
Is it cheaper to rebuild a valve body?
Rebuilding the valve body is a great option that is typically less expensive than purchasing and installing a brand new or remanufactured one. While saving you and your customer money is a great benefit in general, there are situations where rebuilding a valve body is especially appropriate.
Can you rebuild a transmission valve body?
Unless the customer specifies otherwise, the choice to rebuild or replace a failing transmission valve body is your s based on what you discover during disassembly and inspection. You should consider not only the condition of the part itself, but also the vehicle it belongs to, in order to make the best decision for every job and customer. When your trusted team is using quality parts to either replace or rebuild the valve body, your ability to judge the situation is the key to a successful service every single time.
Where is the valve body located on a transmission?
The valve body is usually located inside your automatic transmission case, towards the lower side of the box. You will often see it when you remove the transmission pan. They’re often submerged in transmission fluid and can vary in size depending on the size of the gearbox.
What is a valve body?
Valve Body Function. Your valve body is truly the brains behind the operation however when it comes to automatic gear changing. This ingenious component is made up of a large number of valves and galleries that are used to control gear change so that you, as the driver, don’t have to. These valve bodies are either controlled electronically ...
Why do automatic gearboxes jerk forward?
Instead of smoothly disengaging from one gear and gently engaging the new gear, you may find that your vehicle “snatches” at new gears, causing the car to jerk forwards as it does so.
What makes a gearbox so easy to change?
Since then however, technology has made huge strides in making our gear changing effortless. This is mainly down to the additions to the automatic box itself. Such components as; synchronizers, planetary gears and valve bodies, have allowed for much smoother gear changing as well as better fuel economy. The modern gearbox is highly complex and technical, usually requiring specialists to both diagnose and fix faults.
What does it mean when your car is skipping gears?
Also, if you notice that your gearbox is skipping gears when shifting either up or down , this could also point towards a faulty valve body.
Why does my automatic box slip?
You see, it could be that a valve inside the valve body assembly has started sticking or is no longer fully extending as it should. This could prevent gears from being fully engaged, causing them to slip as you take up the drive.
How does a hydraulic valve work?
These hydraulic systems work by having fluid pushed and pulled around various galleries to engage or disengage certain valves. This system is great and works well as the oil will keep the galleries lubricated and prevent excessive heat build-up.
What Does a Working Transmission Valve Body Do?
Valve bodies in older vehicles use the governor valve and vacuum modulator valve to regulate and manage proper clutch engagement and shifting. The electric valve body use sensors and the electric solenoid valve to control each of gear’s hydraulic circuits. The Hydraulic valve body controls the output for the driver’s manipulation of the gear shift, for example from park to reverse.
What Does Transmission Valve Body Replacement Cost?
According to the American Automobile Association (AAA) the cost for complete transmission valve body replacement ranges from $300 and $1000 on average. For more accurate cost calculations based on your specific vehicle’s make, model, and year use the “Fix or Trade” calculator on their website here.
How to tell if transmission valve is bad?
If you experience any signs of a bad transmission valve body like knocking when changing gears, gears changing unexpectedly, or the RPMs increase when you shift up, a visit to a trusted transmission shop should be on your radar.
Can a transmission valve fail?
Many other valve components housed within the main transmission valve body can fail as well, so diagnosing the specific issue can take sometimes be time-consuming. This is especially true if no issues are found within the main valve body.
What Is a Transmission Valve Body?
It consists of a bunch of valves, solenoids, and passageways that all come together to create a maze-like structure. But despite the complexity of its appearance, the transmission valve body in your vehicle actually has a very simple job: It’s designed to send transmission fluid to wherever it needs to be in order for your transmission to shift from one gear to another.
How long does it take to replace a transmission valve body?
It’s not cheap to do it through a transmission specialist! Even the most experienced mechanics will take anywhere from two to three hours to complete the job from start to finish. This usually drives the cost of it way up.
How Often Does a Transmission Valve Body Need to Be Replaced?
In fact, it’s not uncommon at all for a transmission valve body to last for as long as a car does. You might be able to get away with never having to replace your transmission valve body.
What Are the Common Symptoms of a Bad Transmission Valve Body?
At first, you might hear knocking sounds coming from your transmission that represent a problem with your transmission valve body. But things might also get worse from there.
Is Replacing a Transmission Valve Body on Your Own a Bad Idea?
Have you ever worked on the transmission in your car and done so successfully? If you didn’t just answer that question with a resounding “yes!”, then there is a really good chance that you shouldn’t go anywhere near your transmission in an attempt to replace your transmission valve body. You’re going to be making a big mistake if you do.
Is the Transmission Valve Body Cost Worth It?
But if you plan on keeping your car and driving it for the foreseeable future, it’s going to be a cost that you just can’t get around. It’s well worth it for those who want to be sure their transmission is working properly.
Why is it impossible for a transmission to shift gears?
It’ll be impossible for your transmission to shift gears if your transmission valve body isn’t able to move transmission fluid to the right place.
