how to repair a cracked toilet flange

by Ms. Lysanne Adams IV Published 3 years ago Updated 2 years ago

How To Fix a Broken Toilet Flange

  1. Turn the water supply to the toilet and unscrew the hose. Make sure to empty the tank by flushing the toilet.
  2. Get a paint scraper or a putty knife to remove wax remnants from the flange. Mild detergent can also come in handy to clean wax.
  3. Remove the screws securing the toilet flange to the floor and pry the broken track with a screwdriver so you can slide the repair plate.
  4. If you are going to repair the toilet flange with a repair ring, it is not necessary to remove the flange from the floor.
  5. If you are using replacement toilet flange that is the push-in type, you need to remove the old ring first.
  6. Get the replacement ring and insert it into the opening of the flange and press it down until it is on top of the floor.
  7. Connect the heads of the toilet to the underside of the repair ring or replacement ring tracks. ...

Part of a video titled How To: Easy Repair of a Broken Toilet Flange - YouTube
0:33
13:08
So we're gonna go ahead and install this right now and then I can manage to lift this toilet myselfMoreSo we're gonna go ahead and install this right now and then I can manage to lift this toilet myself go ahead and finish up the job run into a lot back temporarily.

How do you repair a toilet flange?

Toilet flange repair can be daunting but it can also be simple.Today you'll learn how to raise the height of a toilet flange using a toilet flange extender.F...

How do you repair a closet flange?

Remove the Existing Toilet Flange

  • Plug the drain pipe with a towel or old T-shirt. ...
  • Clean the wax ring from the bottom of the toilet and base of the flange by scraping it away with a putty knife or paint scraper.
  • Remove the mounting bolts and screws. ...
  • If you have a gasket-sealed PVC flange, the most common type of flange, simply lift it from the outflow pipe.

More items...

How to repair broken toilet flange?

What you’ll need

  • Wax ring
  • Repair plate
  • Repair ring
  • Screws
  • Paper scraper
  • Screwdriver (plus a slot screwdriver)
  • Hacksaw
  • Pliers
  • Cloth or rag, or newspaper
  • Adjustable pliers

How to replace toilet wax on flange?

Replace the Toilet

  • Place the toilet bowl atop the new flange, aligning the bolt holes in the base of the bowl with the flange bolts. ...
  • Lower the bowl down and apply pressure to set the seal. ...
  • Replace the washers and nuts on each toilet bowl bolt and evenly tighten the nuts onto the bolts. ...

More items...


Can you repair a flange?

1:087:42Toilet Flange Repair Using a Toilet Flange Extender (Step-by-Step)YouTubeStart of suggested clipEnd of suggested clipYou can also get a toilet flange for pair ring this split. Design goes around the waist stack. It'sMoreYou can also get a toilet flange for pair ring this split. Design goes around the waist stack. It's pretty easy to do and this this replaces corroded and rusted metal rings on PVC and ABS flanges.

Will a cracked flange cause a toilet to leak?

Broken, loose, or improperly installed toilet flanges can cause a toilet to leak from the bottom, risking flooding, water damage, or even the release of unwanted sewage and gases into your bathroom.

What causes toilet flange to crack?

Common issues with Toilet Flanges For example, it may break or crack. This is more common if your toilet is loose and rocks back and forth. Eventually, this pressure and stress can cause a full break that will need toilet flange replacement. Also, in some cases your flange may corrode, rust, or deteriorate.

Can you put a new toilet flange over an old one?

Apply a generous bead of 100% silicone caulk on top of the old closet flange. And to the bottom of the new closet flange extender. Either slide the new closet flange bolts into the old flange before adding the extender or add them after you adhere the extender to the old flange.

How much does it cost to have a toilet flange replace?

around $145 to $165If your toilet is creaking or wobbling, you may need to replace the flange. For a plumber, replacing a toilet flange is a quick and easy job. Assuming no other complications pop up, you can expect to pay around $145 to $165 for this simple repair.

How do you use a flange repair kit?

1:1910:00How to Repair a Broken Toilet Flange on Cast Iron, PVC or ABS - YouTubeYouTubeStart of suggested clipEnd of suggested clipUp clean it up as much as it needs to be. So now we have our part which is this is 3d plumbingMoreUp clean it up as much as it needs to be. So now we have our part which is this is 3d plumbing products toilet flange repair kit it's a new product.

How often should a toilet flange be replaced?

Your toilet flange is designed to last for years without causing any problems, but several things can lead to a failed seal in your flange. One of the most common problems you'll run into is with the wax ring, which keeps water from leaking out of the base of your toilet and prevents sewer gas from entering your home.

What happens if toilet flange is broken?

A broken flange will cause the toilet to move because it is no longer secured to the flange, which is anchored to the subfloor. The constant rocking will likely break the wax seal (located between the toilet and the flange), allowing water to leak onto the substrate and the ceiling below when the toilet is flushed.

Should you caulk around toilet flange?

Caulk prevents a fouling area. If mop water, bathtub water, or a less pleasant “bathroom liquid” gets underneath the toilet, there is no way to clean it up. Caulking around the base of the toilet will prevent this from happening.

Are toilet flanges glued?

In addition to being glued to the waste pipe, toilet flanges are typically attached to the bathroom subfloor with screws. Often, there are four screws that attach the flange to the subfloor. All of these must be removed with an electric drill or screwdriver to allow for removal.

Does a toilet flange need to be screwed to the floor?

Closet (toilet) flanges must be 1/4" above a finished floor. This is so the wax ring seals properly to the flange and the hub on the toilet. If a proper seal is not achieved it will result in leaking. If the flange is lower than or flush with the floor they make foam rings that cover the distance for a proper seal.

How do you seal a toilet flange?

3:279:05How To Replace A Toilet Wax Seal OR Rubber Toilet Seal ... - YouTubeYouTubeStart of suggested clipEnd of suggested clipAll you have to do is place it underneath the toilet bowl right there on the ring. Press a littleMoreAll you have to do is place it underneath the toilet bowl right there on the ring. Press a little firmly on it so that it sticks to the bottom. And then just align it with your toilet.

Empty the toilet tank

The first step to take is to shut off the water supply. Locate the shut-off valve on the wall behind the toilet and turn the knob clockwise. After this, flush the water in the tank and use a sponge to absorb the remaining water while pouring it into the bowl. Next, disconnect the water supply from the toilet tank.

Remove the toilet

Unscrew the nuts that hold the toilet to the flange on the floor using a wrench. If either one of them it too rusted to be unscrewed, simply cut it off using a small hand hacksaw because it won’t be reused. Once freed, lift up the toilet and place it aside.

Inspect the flange

Removing the toilet should expose the toilet flange and this should make it easier to spot what the problem is.

Reseat the toilet

After the repair is done, reinsert the toilet seat above the seal and make sure that the screws align with the holes on the toilet. Fit the washers and screw a nut into each bolt so as to fasten the toilet to the floor.

Conclusion

Repairing this component is actually a very easy task and instead of hiring the services of a plumber, you can save that cash by simply learning to do this yourself.

What is a toilet flange?

Learn more... A toilet flange connects the bottom of a toilet to the drainpipe in the floor of the bathroom. When a toilet is leaking from the base, you may need to replace the toilet flange.

How many screws are in a toilet flange?

If so, use a mallet to tap plastic wall anchors into the holes, then drive the screws through the flange lip and into the anchors. Most toilet flanges come with 4 screws, but yours may have more or fewer.

How big should an outflow pipe be?

Measure the interior diameter of the exposed outflow pipe. In most cases, the pipe should measure 4 in (10 cm) in diameter. Jot this measurement down for reference when you go to buy the new flange.

What is the flange made of?

It’s probably either made of PVC but glued to a PVC outflow pipe, or it’s made of cast iron and integrated into the cast iron outflow pipe.

How much does a toilet weigh?

Toilets weigh between 70–120 lb (32–54 kg), so get help if you’re not sure you can lift it. To lift it alone, straddle the bowl, bend your knees, grip the underside of the toilet between the bowl and tank, and lift straight up with your legs (not your back).

Why block sewer pipes?

Blocking the pipe will prevent unpleasant sewer gases from escaping. Some people wait to block up the pipe until after removing the old flange. However, by blocking it now, you stop sewer gases earlier and provide protection against accidentally losing things—wax ring bits, screws, bolts, etc.—down the pipe.

Where to put wax ring on toilet?

However, you can also lay the ring (rounded side up) on top of the toilet flange, then set the toilet on top of it. If you’re using the newer type of “wax ring” that is actually a rubber gasket, lay it rounded side up on the toilet flange and place the toilet on top of it.

Can you repair a cracked toilet flange?

Broken or Cracked Toilet Flange The fix is to replace the entire toilet flange or to use a repair kit to reinforce the broken bolt rail. Sometimes, a small amount of rocking can occur simply because the wax ring is becoming compressed from long use. Try tightening the bolts that hold the toilet to the floor.

Is a cracked toilet flange bad?

Broken, loose, or improperly installed toilet flanges can cause a toilet to leak from the bottom, risking flooding, water damage, or even the release of unwanted sewage and gases into your bathroom. Checking your toilet’s flange should be a staple in your home maintenance checklists.

What causes toilet flange to crack?

Photo 6: Screw on the ring Old cast iron and all-plastic toilet flanges are the most likely to break. The problem is usually caused by rocking toilets or overtightened toilet flange nuts. Look for a cracked or broken rim on the outside of the slots that hold in the bolts (Photos 3 and 4).

Are PVC toilet flanges glued?

In addition to being glued to the waste pipe, toilet flanges are typically attached to the bathroom subfloor with screws. Often, there are four screws that attach the flange to the subfloor. All of these must be removed with an electric drill or screwdriver to allow for removal.

What is a PVC flange?

Sch 80 PVC Flanges Flanges are fittings that connect to pipes to allow the attachment of accessories and other items, stop the flow or increase the strength of the pipe. These discs create a tight seal when pressing two surfaces together using bolts, clamps, edges or a compressive force.

Can I glue down toilet flange?

Buy an inside closet flange. This toilet flange is designed to glue on the inside of the pipe or expand inside the pipe. Leave the old toilet flange right in place and glue on the new one at the right elevation for the floor, if it’s plastic. If it isn’t, then you will have to cut away the old flange.

How much does it cost to fix a toilet flange?

The typical cost to replace a toilet flange is $145 to $165. For a plumber, replacing a toilet flange is a quick and easy job. Assuming no other complications pop up, you can expect to pay $145 to $165 for this simple repair.
