Remove the battery from the bottom of the gun by pressing the release button. After that, empty the nail clip by pulling the nail feed down. Release the flip catch on the gas canister restraint on the rear of the gun and remove the gas canister. It turns out that repairing your Paslode nail gun is not much of a difficult task.
Full Answer
How to clean a Paslode nail gun?
What You Will Need:
- Correct Hex or Allen wrench : A 5/32 inch for cordless, a 9/64 inch for pneumatic
- Lint free rag: to avoid spreading dirt and scratching internal parts
- Paslode lubricating oil
- Paslode degreaser cleaner
How to clean the Paslode Impulse framemaster Nailer?
Restrict DIY maintenance to the following areas:
- Get the right supplies Paslode Cordless Lubricating Oil Part No. B20544F Paslode Cleaner Degreaser Part No. ...
- Conduct a general assessment We recommend tightening all screws and bolts in your nailer every month. ...
- Check the battery Inspect the battery indicator when battery is fitted, it should be flashing green for a charged battery. ...
How to service a Paslode framing gun?
Paslode nail gun repair manual –other Paslode pneumatic framing nailer troubleshooting guidelines. Paslode pneumatic framing nailer won’t fire at all-A nail jam may be preventing the fasteners from moving forward (clear the jam), its fuel cell may be out-of-date (replace) or not attached properly (fix this), or even empty (refill).
How to lubricate finish Nailer?
Oil should be added to the gun’s moving parts and the fitting at the bottom of the tool. Proper lubrication will keep the tool running smoothly. If the nail gun will be used all day long, oil may need to be reapplied throughout the day. Be sure to also apply oil to the air fitting each day (about 4-5 drops).
Why is my Paslode finish nailer not firing?
Possible causes for a Paslode nail gun not firing are: A nail jam is stopping the nails from moving forward. The gas fuel cell is empty, out-of-date or not attached properly. The wrong type of Paslode nails are being used.
How do I fix my Paslode nail gun?
0:5512:39How To Service Your Paslode Cordless Framing Nailer ... - YouTubeYouTubeStart of suggested clipEnd of suggested clipFirst thing we're gonna do is we're gonna remove these two 5/32 fasteners okay we'll put them aside.MoreFirst thing we're gonna do is we're gonna remove these two 5/32 fasteners okay we'll put them aside.
How do you take apart a Paslode framing nailer?
3:4711:14How to Service a Paslode Framing Gun - YouTubeYouTubeStart of suggested clipEnd of suggested clipWe can then loosen the two screws on the side of the cylinder head we do this so the cylinder headMoreWe can then loosen the two screws on the side of the cylinder head we do this so the cylinder head it's got a bit of movement in it so you don't bend the fan blades when you take the tool apart.
Why is my nailer not working?
Jams are the most common cause of a nailer not firing. Thankfully, they are often easy to clear. For safety, first disconnect the tool from the air supply, retract the feeder mechanism, and remove any excess fasteners from the magazine. From there, clearing the jam depends on what type of nailer you have.
How do you fix a nail gun?
4:206:10How to Fix a Nail Gun! - YouTubeYouTubeStart of suggested clipEnd of suggested clipWell I had the system cranked down to 60 psi I've run wrapped it up to 110 let's see how that works.MoreWell I had the system cranked down to 60 psi I've run wrapped it up to 110 let's see how that works. Well it worked but no nail came out.
Why is my Paslode gun flashing red and green?
Look at the lights on the charger unit – an alternating flashing red and green light means that the battery is faulty. In this instance take the battery back to the dealer that you bought it from and they should be able to help you.
How do you assemble a Paslode finish nailer?
4:106:11Cleaning & Maintaining Paslode Cordless Finish Nailers - YouTubeYouTubeStart of suggested clipEnd of suggested clipTo reassemble the tool align the cylinder head tabs to the motor. Rotate the cylinder head 1/8 turnMoreTo reassemble the tool align the cylinder head tabs to the motor. Rotate the cylinder head 1/8 turn counterclockwise to lock it in place. Now reconnect the wiring harness. And spark plug wire.
How often should you service a Paslode nail gun?
Maintaining and cleaning a cordless nailer takes about 15 minutes, once every 6 months or 50,000 nails—that's all. To keep a Paslode cordless framing nailer in prime condition, watch the step-by-step Paslode video.
How do you change the spring on a Paslode framing gun?
1:073:57How to Change the Follower Spring and Core on a Paslode IM65 Nail GunYouTubeStart of suggested clipEnd of suggested clipPlace the spring into the left handle body to disconnect the follower and follow a core use an allenMorePlace the spring into the left handle body to disconnect the follower and follow a core use an allen key or small tool to push out the follower.
How long does a Paslode nail gun last?
The XP comes with a 7v lithium-ion battery, which Paslode claims can last long enough to shoot up to 9,000 nails before needing to be recharged.
How does a Paslode nail gun work?
When the trigger is pulled, a spark plug ignites the fuel charge, pushing the piston and connected drive pin to the bottom of the chamber and driving a nail. A small amount of combustion gas is briefly stored in a side chamber and is used to push the piston back into the ready position after the nail is driven.
How do you clean a Paslode nail gun?
0:073:54How to clean the Paslode Impulse Framemaster Nailer - YouTubeYouTubeStart of suggested clipEnd of suggested clipWe get a nice clean rag. And we just gently dab around the fan blades.MoreWe get a nice clean rag. And we just gently dab around the fan blades.
Why is my Paslode nail gun not firing?
Possible causes for a Paslode nail gun not firing are: A nail jam is stopping the nails from moving forward. The gas fuel cell is empty, out-of-date or not attached properly. The wrong type of Paslode nails are being used.
Why are my nail gun o rings broken?
The o-rings around the nail gun’s firing pin are broken. Possible causes for this are: General wear and tear. The o-rings have previously been removed and not put back correctly.
Can a Paslode nail gun be used for power tools?
Paslode nail guns are extremely robust and designed to withstand tough working conditions. However, like any power tool, they can still experience issues. These are the most common Paslode problems we see.
Can Paslode be used with other brands?
Paslodes can also experience problems when they’re used with other brand’s (including fakes) batteries, nails, gas, etc. As Paslode haven’t tested these third party products, they can’t say whether they’re compatible or even safe to use with their tools.
