Plantronics Voyager legend Reset Eliminate the Plantronics headset from your phones paired devices Power your mobile phone off, then, at that point, power it back on Pair your Plantronics headset back to your PDA (follow manual if uncertain how) Your Plantronics headset should now be reset
Full Answer
How to connect Plantronics headset to computer?
Place your headset into pairing mode. On your computer, click Start, and then click Devices and Printers. Note: Depending on your computer's configuration, you may first have to click Control Panel, then Devices and Printers. Click Add a Device. The Add a Device windows appears, and immediately starts searching for your headset.
How to pair your Plantronics Bluetooth?
To pair your Plantronics Bluetooth headset with your iPhone:
- On your iPhone, press Settings > General > Bluetooth.
- If Bluetooth is turned Off, tap to turn it On.
- Place your Bluetooth headset into pairing mode.
- When you see your Plantronics device name, tap it to pair and connect.
How to pair Plantronics Bluetooth with iPhone?
To successfully pair your headset with your phone, follow the steps set out below:
- Start with your Plantronics Headset switched off.
- Turn on the Bluetooth feature on your iPhone. ...
- Make sure that the Bluetooth setting is turned On.
- The iPhone will automatically search for any devices within range that are emitting the Bluetooth signal. ...
- Turn on the pairing mode on your Plantronics headset.
How to sync Plantronics headset?
- If your headset is initially in the power off condition, you need to put in on. ...
- Hold the call answer button for 5 to 6 seconds until you see the LED light flashing. ...
- The third step is related to searching the headset on the smartphone. ...
- If you are required to enter a passcode, simply enter four zeroes [0000] and the connection would be established.
See more
Can Plantronics headset be repaired?
Plantronics will, at their option, repair or replace the Products that do not conform to the warranty. Plantronics may use functionally equivalent reconditioned/refurbished/re manufactured/pre-owned or new Products or parts.
How do I reset my Plantronics Voyager Legend?
Plantronics Voyager Legend Reset: A How-To GuidePerforming the Reset. Turn your Plantronics Voyager off. The on/off button is the slide switch on the back of the headset just above the charging contacts. ... Your Voyager should now be reset and ready to work with your Bluetooth devices. Turn it on to see if it works!
How do I fix my Plantronics headset?
In the Device Manager window, find the Sound, Video and Game Controllers option and expand it. Right click on your Plantronics device and select "Uninstall". Unplug the headset and restart the PC. After the PC has rebooted, reconnect the headset.
Is the Plantronics Voyager Legend discontinued?
The Voyager Legend UC and Voyager Legend CS products are going end of life. The last order will be April 30, 2020 and last ship date of May 29, 2020, or while supplies last. For suggested replacement products, see info below.
How do I fix my Plantronics Bluetooth headset?
How to Fix a Plantronics BluetoothCharge your headset's battery. ... Reboot your devices. ... Uninstall problematic software. ... Make sure your phone's Bluetooth settings are correctly enabled. ... Rule out radio interference. ... Call Plantronics directly.
How do I update the firmware on my Plantronics Voyager Legend?
To update your headset:Connect your headset to its USB charging cable or place the headset in the optional desktop charge stand. ... Choose Voyager Legend, and then click Get Started.Click Continue.Click Continue again.Personalize any of your settings, if desired.Click Update Your Headset.Click Update.More items...•
Why won't my Plantronics headphones turn on?
If your headset seems to charge (i.e., the light turns on), but then won't power on, try resetting the headset. While pressing the power button, plug in the AC charger. The light on the headset should turn on. Once the light turns on, let go of the power button.
Why can't I hear anything on my Plantronics headset?
Unable to Hear Caller or a Dial Tone The headset battery may need to be charged. The USB Bluetooth adaptor may not be set as the default audio device. Use the audio settings in Windows under Sounds and Audio Devices to select "Plantronics BT Adaptor" as the audio device. The listening volume may be too low.
Why is my Plantronics headset mic not working?
Make sure the USB connection is not loose. If the USB connection is secure, but the issue persists, try connecting to a different USB port. Wait for your computer to recognize the USB connection, and then test the microphone again. Make sure that your Plantronics headset is selected as the default audio device.
What is the difference between Plantronics legend and 5200?
Our Verdict Both headsets share almost the same design and feel equally comfortable, well-built, and stable, except the 5200 charges via Micro-USB while the Legend uses a proprietary magnetic charging clip. The 5200 has a better-balanced sound profile for phone calls, resulting in less piercing and painful voices.
How do I put my Plantronics Voyager in pairing mode?
Turn the headset on and then put it on. Tap the voice button and then say "pair" or press and hold the call button until you hear "pairing." Activate Bluetooth on your phone and set it to search for new devices.
How do I use my Plantronics Voyager Legend?
3:215:12Voyager Legend UC Video Setup Guide - YouTubeYouTubeStart of suggested clipEnd of suggested clipAuto call answer automatically answers an incoming call from your mobile phone or PC. By simplyMoreAuto call answer automatically answers an incoming call from your mobile phone or PC. By simply putting on the headset.
How do I put my PLT legend in pairing mode?
Voyager Legend: How to PairTurn the headset on and then put it on.Activate Bluetooth on your phone and set it to search for a new device.Select "PLT_Legend." If your phone asks for a passcode, enter four zeros (0000); otherwise, accept the connection. ... Once successfully paired, you will hear "pairing successful."
How do I reset my Plantronics USB dongle?
Resolution: Reset the headset and USB Bluetooth adapter. Remove the USB Bluetooth adapter from the USB port for 5 seconds and then plug it back in. Power on the headset. Wait 5 seconds.
How do I put my Plantronics headset in pairing mode?
Press and hold the call control button for about 5-6 seconds until the light on the headset starts flashing an alternating red-blue. Release the button and set the headset aside. On your cell phone, go to the Bluetooth menu and search for (or add) a device. The cell phone should find the headset.
How do I pair my Plantronics Legend headset?
How to Pair the Plantronics Voyager Legend Bluetooth Headset Turn the headset on. Slide the power switch to the 'on' position showing green. ... Turn on your phone's Bluetooth feature. ... Select Voyager Legend. ... Complete pairing process.
When was the Plantronics Voyager Legend released?
Plantronics Voyager Legend Troubleshooting. The Plantronics Voyager Legend is a Bluetooth headset that was originally released in September, 2013. With talk time up to 7 hours and a range of 33 feet, the popularity of this device is only rivaled by customer satisfaction with the product. Author: JS (and 4 other contributors)
What happens if the battery is not working on a Voyager?
If the battery is not the problem, it is likely that the main circuit board has malfunctioned and needs to be replaced. Follow the steps in the Plantronics Voyager Legend battery replacement guide to locate the main circuit board, on which the battery is attached, to replace the circuitry.
How many sections does the Voyager Legend have?
The Plantronics Voyager Legend is comprised of three swiveling sections . The movement allotted by these different sections allow it to be placed on either the left or right side of the head. Try rotating the different segments slightly to see if a better fit can be achieved.
What could have caused a short in the Voyager battery?
Water damage to battery. Water damage could have caused a short in the battery. Replace the battery by following the Plantronics Voyager Legend battery replacement guide.
Introduction
The microphone assembly is easily distinguished by its "boom-like" shape. The actual assembly is comprised of a voice-tube, and a circuit board system. The microphone replacement guide will detail how to carefully disassemble the microphone unit, and remove and replace the different components that comprise it.
Step 2
Reveal the metal, protective plate by completely removing the top piece of the plastic housing.
Step 3
Locate the volume button at the rear of the microphone assembly, near the earpiece assembly.
Step 7
To reassemble your device, follow these instructions in reverse order.
Introduction
The earpiece unit on the Plantronics Voyager Legend consists of a soft-plastic earpiece, a plastic housing, a wire assembly, and the actual speaker unit. The assembly is held together by glue and snaps making disassembly difficult.
Step 2
Heat the earpiece assembly with a heat gun (a hair dryer will work if a heat gun is not available).
Step 3
The two snaps that combine with the adhesive to hold the assembly together are located in the neck of the earpiece unit.
Step 6
Use Precision Tweezers to remove the protective screen from the front of the speaker unit.
Step 7
To reassemble your device, follow these instructions in reverse order.
What is a Voyager Legend?
The Plantronics Voyager Legend is a Bluetooth headset, with user-friendly features such as extended battery life and an easy-to-use magnetic charging port . Because of these features, power problems can be handled accordingly, to ensure a longer life for the device.
How to dislodge snaps on a spudger?
Use the flat end of a spudger to begin dislodging the snaps, starting at the opposite end of the charging port. Work evenly around the circumference of the housing, until all snaps are free. Lift the plate off of the housing. Edit.
Why would one reset their Voyager Bluetooth Headset?
Even the best electronics can get glitches, and the Plantronics Voyager series is no exception. Luckily, there are ways to make it work the correct way, which we have here.
Hi, I'm Kyle!
I manage this blog. Feedback, comments, complements, criticisms, or any other questions? I'll take them all!
First Time Pairing for the Voyager Legend Headset
1) Turn the headset on. Slide the power switch to the ‘on’ position showing green. The headsets LEDs will begin flashing red/blue. The Voyager Legend headset is now in pairing mode. If you don’t see the red/blue flashing LED, turn the headset off and repeat step 1.
To Pair Voyager Legend to a Different Phone or Re-Pair to the Same Phone
1) Turn the headset on. Slide the power switch to the ‘on’ position showing green.
